TD1 Refrigeration Expansion Valve
7 day ago
Danfoss Type TD 1 Thermatic Expansion Valves Angle Internal Type
Product introduction
TD 1 is a Danfoss Type thermostatic expansion valve that regulates the injection of refrigerant into the evaporator. The injection amount depends on the refrigerant superheat at the evaporator outlet, so a bulb must be installed. TD 1 is suitable for hermetic systems.
Application examples:
1. GDM (Glass Door Merchandisers)
2. Commercial Refrigerators and Freezers
3. Heat Pumps
Main technical parameters
|
Type
|
Flow Direction
|
Port (ODF)
Inlet x Outlet
|
Equalization
|
Refrigerant
|
Orifice No
|
|
TD 1
|
Angle
Straight
|
1/4'' x 3/8''
(6mm x 10mm)
|
Internal
|
R134a
R22
R404a
R407C
|
0
1
2
3
4
5
|
|
3/8'' x 1/2''
(10mm x 12mm)
|
|
Orifice no
|
Rated capacity in tons (TR)
|
Rated capacity in kW
|
||||||
|
R134a
|
R22
|
R404a
|
R407C
|
R134a
|
R22
|
R404a
|
R407C
|
|
|
0
|
0.13
|
0.23
|
0.24
|
0.26
|
0.46
|
0.82
|
0.83
|
0.9
|
|
1
|
0.2
|
0.34
|
0.32
|
0.37
|
0.7
|
1.19
|
1.13
|
1.31
|
|
2
|
0.34
|
0.54
|
0.51
|
0.59
|
1.19
|
1.89
|
1.78
|
2.09
|
|
3
|
0.57
|
0.84
|
0.67
|
0.92
|
2.01
|
2.95
|
2.37
|
3.24
|
|
4
|
0.8
|
1.16
|
0.95
|
1.28
|
2.83
|
4.10
|
3.36
|
4.51
|
|
5
|
1.08
|
1.83
|
1.635
|
2.01
|
3.81
|
6.43
|
5.79
|
7.08
|
Main Dimension
Brass valve body
The body of TD 1 is made of solid brass and the connection method is flare, which makes the valve installation more stable and not easy to be damaged during operation.
Stainless Steel Material
It is made from stainless steel for extreme durability and also has interchangeable hole components for quick and easy installation.
Wide range of application
Generally suitable for refrigeration and air conditioning equipment, especially for ''dry'' evaporators, the superheat at the evaporator outlet is proportional to the evaporator load.
Pay Attention:
◆ Please check whether the product is intact before use
◆ Please confirm that the installation conditions are in accordance with the specifications
◆ Please use in a stable environment
◆ Pay attention to clean up dust and other things that affect operation
