SE3 Slewing Bearing

Solar tracker must have smooth, slow and sturdy motion. The tracker should possess high position accuracy and high degree of reliability. These requirements can be attained by specially designed drivers known as slewing drivers.

Accuracy: 0.1 Degree

Available: 3 inch - 21inch

Horizontal installation

It is advised to mount the slewing drives upside down on the azimuth axis in solar applications for better protection and add protection for the elevation axis. For other applications, the mounting directions shall be based on the evaluation of the protection level and it shall be better for better protection.

Vertical installation

It is advised to mount the slewing drives referring to attached drawing upside in solar applications for better protection. For other applications, the mounting directions shall be based on the evaluation of the protection level and it shall be better for better protection.

1. By adopting slewing bearing as its core component, slewing drive can bear axial force, radial force and tilting moment simultaneously.
2. Slewing drive is widely applied in modular trailers, all types of cranes, aerial working platform, solar tracking systems and wind power systems.
3. Electric and planetary gearboxes can be designed according to customer's requirement.
4. Slewing drive has the advantage of saving space in facilities, max load capacity in a compact design, extensive lifespan, reduced maintenance costs, etc.

SE3 Slewing Bearing: Technical Overview & Application Guide

I. Product Overview

TheSE3 slewing bearingis ahigh-precision, heavy-duty turntable bearingdesigned for applications requiringaxial/radial load support, simultaneous rotation, and compact design. It integratesgearing, sealing, and lubrication systemsinto a single unit, offeringhigh reliability, low maintenance, and customizable specificationsfor industries likeconstruction machinery, wind turbines, robotics, and aerospace.

------

II. Core Parameters & Performance

【表格】

 Specification Technical Details Explanation

Bearing Type Single-row/Double-row Ball/Roller Single-row for light-duty, double-row for heavy-duty.

Outer Diameter (D) 300–3000 mm (customizable) Suitable for small to large-scale machinery.

Bore Diameter (d) 100–2500 mm Matches shaft/gearbox connections.

Height (H) 50–300 mm Compact design for space-constrained applications.

Dynamic Load Rating 50–5000 kN (axial/radial) Handles high-impact, cyclic loads in construction/mining.

Static Load Rating 100–10,000 kN (axial/radial) Supports stationary loads in wind turbines/heavy machinery.

Gear Type External/Internal Gear (Module 2–12) External gear for easy drive integration; internal for compactness.

Sealing System Double-lip rubber seals Prevents dust/water ingress (IP66/IP67 optional).

Lubrication Method Grease/Oil circulation Grease for simplicity; oil for high-speed/temperature applications.

Material 42CrMo/50Mn alloy steel High-strength, heat-treated steel for durability.
