Aluminum tube horizontal wrapping machine

6 month ago

2 0 

Shandong Dyehome Intelligent Equipment Co., Ltd.

8 year

Product details

Specialized Packaging Equipment for Long Products

The horizontal ring stretch wrapping machine is specifically developed for long items like profiles, pipes, boards, and rods. Compared with traditional manual strapping or bagging, it uses a rotary ring mechanism to wrap film 360° around the product, providing full protection against friction, rain, and contamination during handling and transport. It can be integrated with automatic conveyor lines to achieve high-speed, unmanned operation, significantly improving packaging efficiency and consistency. It is particularly suitable for bulk shipments of steel pipes, aluminum profiles, timber, plastic pipes, and cables.

automatic horizontal stretch film wrapping machine

Automated Operation – Stable, Efficient, and Cost-Saving

Equipped with a PLC programmable control system and user-friendly touch screen interface, the machine supports multiple wrapping modes and adjustable overlap and wrapping cycles. The photoelectric sensor detects product positioning for automatic continuous operation. The film carriage features automatic reset and a pre-stretch unit that increases film utilization and reduces material costs. Wrapping materials can include stretch film, non-woven fabric, composite paper, or woven tape, allowing flexibility based on product characteristics. The finished package forms a tight spiral wrap that is both attractive and protective—dust-proof, moisture-resistant, and scratch-resistant—while making products easier to stack and transport.

Comprehensive Specifications for Diverse Needs

Applicable wrapping size: W(300–650)mm × H(350–650)mm; wrapping material width: 100–300mm; wrapping speed: 19–57 rpm; conveyor speed: 6–12 m/min. Roller load capacity: 100–1000 kg; total power: 3 kW; power supply: 380V/50Hz; machine weight: approx. 1000 kg; conveyor width: 900 mm. Optional configurations include roller conveyors, rubber-coated roller lines, and belt conveyors for fully automated in-line packaging. Customized larger models can also be supplied to meet the special needs of building material plants, steel pipe manufacturers, and large logistics warehouses.

The horizontal ring stretch wrapping machine not only reduces labor intensity and material waste but also helps enterprises establish standardized and scalable packaging systems. It is widely applied in industries such as glass products, paper, textiles, chemicals, metal products, building materials, and electronics.
Shandong Dyehome Intelligent Equipment Co., Ltd. as a professional packaging equipment manufacturer, is ISO9001 and CE certified. Its products are exported worldwide and support full customization, on-site installation, commissioning, and technical training, providing customers with efficient, intelligent, and energy-saving packaging solutions.
