Dacar535 Male Female HSD Cable

4-Pin Straight Screw-Type HSD LVDS Male Solder Cable Mount Connector for Dacar 535

Overview:

This 4-pin straight HSD LVDS male connector features a screw-type locking mechanism and is specifically designed for solder termination onto Dacar 535 coaxial cable. Engineered for high-speed differential data transmission, it is ideal for automotive LVDS video systems, infotainment modules, and camera interfaces.

Key Features:

• Connector Type: HSD Male – 4 Pin (Straight)

• Locking Mechanism: Screw type for secure and vibration-resistant connection

• Termination Style: Solder type for custom cable mounting

• Cable Compatibility: Dacar 535 (automotive-grade low-loss coaxial cable)

• Signal Type: LVDS (Low Voltage Differential Signaling)

• Impedance: 100 ohms (differential pair)

• Frequency Range: Up to 6 GHz

• Shielding: 360° full metal shielding for EMI/RFI protection

• Durability: >100 mating cycles

• Temperature Range: -40°C to +105°C

• Compliance: RoHS, automotive OEM standards

Applications:

• Automotive LVDS camera systems (rear view, 360° surround view)

• Infotainment and multimedia systems

• Head unit to display/control module interfaces

• High-speed data transmission in harsh environments

Benefits:

• Secure screw-lock design prevents loosening from vibration

• Compatible with Dacar 535, ensuring high signal integrity

• Robust shielding for interference-free video/data performance

• OEM-grade durability for long-term automotive use

Let me know if you need matching female connectors, angled versions, or pre-assembled cable harnesses. We can also supply Fakra connector, Mini Fakra connector, HSL connector, RF connector and so on.
