Inconel Alloy 600 Heat Exchanger Tube
Inconel 600 heat exchanger tubing is a nickel-chromium alloy with excellent strength, high-temperature resistance, and corrosion resistance. Due to its unique combination of properties, it is commonly used in heat exchanger tubing and is well-suited for demanding applications. The alloy's high-temperature resistance enables it to withstand extreme temperature conditions, making it an ideal choice for heat exchangers operating at high temperatures. Furthermore, Inconel 600 heat exchanger tubing's corrosion resistance enables it to withstand a wide range of corrosive environments, including acids, bases, and chloride ions. This corrosion resistance helps maintain the integrity and service life of heat exchanger tubing, reducing the risk of failure and improving overall performance.
Furthermore, the alloy's excellent mechanical strength and oxidation resistance further contribute to its widespread use in heat exchanger applications. These properties enable Inconel 600 heat exchanger tubing to withstand high-pressure conditions and maintain its structural integrity even after prolonged exposure to high temperatures and harsh environments. Its combination of high-temperature resistance, corrosion resistance, and mechanical strength makes Inconel 600 a reliable choice for heat exchanger tubing, ensuring efficient heat transfer and long-lasting performance.
Specification Of Inconel 600 Heat Exchanger Tube
| Standard | ASTM B163, B516 / ASME SB163, SB516 |
| Item | Heat Exchanger Tube |
| Heat Exchanger Tube Sizes | 3/8″ OD to 3″ OD (Imperial and Metric sizes) |
| Heat Exchanger Tube Thickness | 0.7mm to 4mm |
| Heat Exchanger Tube Length | 3 MTRS, Custom Length |
| Test Certifcate | EN 10204 3.1 |
Chemical Composition Of Inconel 600 Heat Exchanger Tube
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Inconel 600 Heat Exchanger Tube Sizes & Thickness
| Tube | Outside diameter | Wall thickness | |||
| Size | inch | mm | BWG | inch | mm |
| 1/4 " | 0.250 | 6.350 | 22 | 0.028 | 0.711 |
| 24 | 0.022 | 0.559 | |||
| 3/8 " | 0.375 | 9.525 | 18 | 0.049 | 1.245 |
| 20 | 0.035 | 0.889 | |||
| 22 | 0.028 | 0.711 | |||
| 1/2 " | 0.500 | 12.700 | 18 | 0.049 | 1.245 |
| 20 | 0.035 | 0.889 | |||
| 5/8 " | 0.625 | 15.875 | 16 | 0.065 | 1.651 |
| 18 | 0.049 | 1.245 | |||
| 20 | 0.035 | 0.889 | |||
| 3/4 " | 0.750 | 19.050 | 12 | 0.109 | 2.769 |
| 14 | 0.083 | 2.108 | |||
| 16 | 0.065 | 1.651 | |||
| 18 | 0.049 | 1.245 | |||
| 20 | 0.035 | 0.889 | |||
| 7/8 " | 0.875 | 22.225 | 14 | 0.083 | 2.108 |
| 16 | 0.065 | 1.651 | |||
| 18 | 0.049 | 1.245 | |||
| 20 | 0.035 | 0.889 | |||
| 1 " | 1 | 25.400 | 12 | 0.109 | 2.769 |
| 14 | 0.083 | 2.108 | |||
| 16 | 0.065 | 1.651 | |||
| 18 | 0.049 | 1.245 | |||
| 1 1/4 " | 1.250 | 31.75 | 10 | 0.134 | 3.404 |
| 12 | 0.109 | 2.769 | |||
| 14 | 0.083 | 2.108 | |||
| 16 | 0.065 | 1.651 | |||
| 2 " | 2.000 | 50.800 | 12 | 0.109 | 2.769 |
| 14 | 0.083 | 2.108 | |||
About Gnee Steel
Gnee Steel is a company specializing in the production and sale of various nickel-based alloys, including Nickel 201, Nickel 202, Hastelloy C-276, Hastelloy C-22, Hastelloy B, Hastelloy C-4, Inconel Alloy 600, Inconel 625, Inconel 718, Inconel X-750, Incoloy Alloy 800, Incoloy 800H/HT, Incoloy 825, Monel Alloy 400, Monel K500, and high-temperature alloys. Genie Steel's products are widely used in aerospace, chemical, electric power, automotive, nuclear energy, and other fields, and we can provide customized alloy material solutions based on customer needs. For alloy material pricing inquiries or customized alloy material solutions, please feel free to contact us for a quote.
