HUS-R Military standard Heat shrink tube

Military grade heat shrink tube

  The military grade heat shrink tube is co-extruded from cross-linked Polyolefin PE and EVA Flame retardant, with the outer Polyolefin being the insulating Flame retardant material. The inner layer Hot melt adhesive can buffer mechanical strain and has strong sealing performance. It is produced in accordance with the Military standard. It is applicable to all kinds of Wiring harnesses, Marine electric wires, cables, and metal pipes where sealing, waterproofing, moisture-proofing and anti-corrosion are required.

Features & Benefits:
1, Meet the military standard ASM-DTL-23053/4
2, Flame-resistant inner layer, anti-UV
3, Heat shrink ratio: 3:1, 4:1
4, Waterproof, Damp-proof, anti-corrosion, prevent gas leakage

Operating Indexes:
1, First shrink temp.: 70℃
2, Final shrink temp.: 125℃
3, Working temp.:-45℃~135℃

Up to standard: Approvals
 Meet military standard ASM-DTL-23053/4, UL224, 600V

Standard color: Black. Other colors can be customized.

The specified size and cutting can be provided separately according to the customer's special requirements
