1. Model Definition and Classification
1.1 Model Identification
• Possible Interpretations:
• Excavator Model Association: If "800/1200" refers to Komatsu excavator series (e.g., PC800, PC1200), the relief valve is a hydraulic component for these models.
• Pressure Rating Indication: If indicating pressure ranges (e.g., 800 bar/1200 psi), confirm with product specifications.
• Internal Code: Komatsu may use "800/1200" as a series code for relief valves (e.g., KMSV-800/KMSV-1200).
Recommendation:
• Prioritize official Komatsu part numbers (e.g.,705-12-31420for PC800 valves).
• If unavailable, use:"Komatsu Compatible Relief Valve for PC800/PC1200".
1.2 Valve Types
Based on hydraulic system functions, possible types include:
• Main Relief Valve: Limits maximum system pressure to protect hydraulic pumps from overloading.
• Pilot-Operated Relief Valve: Uses a pilot oil circuit for faster response and precise control.
• Proportional Relief Valve: Supports electronic pressure adjustment for advanced applications.
------
2. Core Functions and Technical Specifications
2.1 Functional Description
• Pressure Protection: Opens when system pressure exceeds the preset value, diverting excess hydraulic oil back to the tank to prevent pipeline or component failure.
• Pressure Stabilization: Maintains stable pressure during load variations, ensuring normal operation of actuators (e.g., hydraulic cylinders, motors).
• Remote Pressure Adjustment(select models): Enables pressure regulation via external pilot circuits.
2.2 Key Specifications (Example)
【表格】
Parameter Description
Model Komatsu 705-12-31420 (Example)
Applicable Models PC800-8, PC1200-8 Excavators
Rated Pressure 35 MPa (350 bar) / 5,000 psi
Flow Range 100–300 L/min (Adjustable per model)
Adjustment Method Manual knob (Range: 20–35 MPa) or electronic proportional control
Port Connections Inlet: M30×2 thread; Outlet: G1/2 thread
Material Valve body: Cast steel; Seals: Nitrile butadiene rubber (NBR)
Operating Temp. -20°C to +80°C
Certifications ISO 9001, CE
------
3. Applications and Troubleshooting
3.1 Typical Applications
• Excavator Hydraulic Systems: Installed at the main pump outlet for circuit protection.
• Hydraulic Breaker Circuits: Limits impact pressure to prevent hammer damage.
• Crane Luffing Systems: Controls luffing cylinder pressure to avoid overloading.
3.2 Common Failures and Solutions
【表格】
Symptom Probable Cause Solution
Insufficient Pressure Low relief valve setting or stuck spool Readjust pressure; clean spool and replace seals
Pressure Fluctuation Fatigued spring or contaminated pilot line Replace spring; clean pilot valve and filter
Frequent Valve Opening Overload or worn spool Check load limits; replace spool assembly
Oil Leakage Aged O-rings or cracked valve body Replace seals; repair or replace valve body
