Product details
Multi effect wastewater evaporators play a very important role in industrial wastewater treatment and environmental protection, and their main functions can be summarized as the following core aspects:
Efficient concentration of wastewater, significantly reducing the volume of wastewater:
This is its most basic and important function. It utilizes steam heat energy to evaporate a large amount of water in wastewater (turning it into steam condensate) through multiple "effects" running in series.
Effect: It can concentrate the originally large volume of wastewater into a highly concentrated liquid (mother liquor) with a very small volume (usually only 5% -20% of the original volume, or even lower). This greatly reduces the cost and burden required for subsequent processing or disposal.
Recycling high-quality distilled water (chilled water):
The water vapor (secondary steam) generated during the evaporation process will be condensed in the subsequent heating chamber or specialized condenser.
Effect: High purity condensed water (distilled water) is obtained. These waters usually have excellent water quality (low salt content, low COD/BOD, low heavy metals, etc.), and can:
Directly reused in the production process, such as boiler makeup water, cooling water, process water, etc., to achieve water resource recycling and save fresh water consumption.
Standard emissions: Meet strict emission standards and directly discharge into the environment.
Further advanced treatment (if higher water quality is required).
Enrichment and separation of valuable dissolved solids:
As water evaporates, the concentration of dissolved salts, minerals, or other valuable substances (such as sodium chloride, sodium sulfate, ammonium nitrate, certain metal salts, etc.) in wastewater continues to increase.
Effect:
Eventually, it reaches supersaturation in the final stage or specialized crystallizer, and crystallizes to precipitate solid products.
These crystalline salts or solid substances can be separated (such as centrifuges, filters) and recycled as valuable by-products (such as industrial raw materials), or safely disposed of (such as landfill), greatly reducing the difficulty and cost of solid waste treatment.
Significant energy savings (one of the core advantages):
The essence of multi effect evaporation lies in the cascading utilization of energy. The first effect uses fresh steam (primary steam) to heat wastewater, producing secondary steam.
This part of the secondary steam is not discharged as waste heat, but serves as a heating source for the second effect. Similarly, the secondary steam generated by the second effect heats up the third effect, and so on.
Effect: Each kilogram of fresh steam can evaporate several kilograms (theoretically equal to the effect number) of water in wastewater. For example, a three effect evaporator theoretically only requires about 1/3 kilogram of fresh steam to evaporate 1 kilogram of water. Compared to single effect evaporation, the energy efficiency (the amount of water evaporated per unit of steam consumption) is doubled, and the operating energy consumption is significantly reduced, which is the key economic factor for its widespread application.
The core process for achieving "zero discharge" or near zero discharge of wastewater:
For wastewater with high salt content, high toxicity, difficult degradation, or extremely strict discharge standards (such as coal chemical wastewater, desulfurization wastewater, garbage leachate, and some pharmaceutical wastewater), traditional biochemical treatment is difficult to meet the standards.
Effect: Multi effect evaporation concentration (often combined with other membrane technologies such as reverse osmosis and crystallization) can completely separate water and dissolved solids in wastewater, ultimately achieving:
Recycle most of the clean water (distilled water).
Produce high-purity solid salts (which can be resourceful or safely disposed of).
A very small amount of highly toxic concentrated residue (if any) requires specialized treatment.
Thus meeting the requirement of "zero liquid discharge" and completely eliminating the environmental risks of wastewater discharge.
Improve the stability and reliability of wastewater treatment systems:
It can effectively treat wastewater with large fluctuations in water quality, high salt content, poor biochemistry, and complex composition.
Effect: The physical process is less affected by the biochemical characteristics of wastewater, and the operation is relatively stable and reliable.
In summary, the main function of a multi effect wastewater evaporator is to:
Concentrate wastewater efficiently and energy-saving (significantly reducing capacity).
Recycling high-purity distilled water (resource utilization).
Separate and recover valuable dissolved solids (resource utilization).
Reduce the cost and difficulty of subsequent processing and disposal.
It is one of the key technologies to achieve the goal of "zero discharge" of high salt and difficult to degrade wastewater and meet strict environmental regulations.
Its core value lies in the efficient cascade utilization of energy to effectively separate water and dissolved solids in wastewater at a lower cost, while achieving reduction, resource utilization, and harmlessness. It is an important equipment for modern wastewater management and resource recovery.
