Hybrid 1kW 48V Inverter 24V 48V MPPT Solar+Grid Charger 120A 5KW 6KW AC Single Phase Output Warranty Global Voltage Support1

2 week ago

1 0 

3 year

Product details

	Parameter name	1.2KW	3.6KW	6KW
AC Input	Main topology	L+N+PE
AC Input		Nominal Voltage	230V
	Input Voltage Range	90~280V 170~264V
	Frequency Range	40-70Hz(APP MODE/GEN MODE) Set Frequency(50Hz or 60Hz)±10Hz(UPS MODE )
	Power Fa ctor	≥0.9	≥0.99	≥0.99
PVInput	Max Voltage	115V	500V	500V
	Max input current	18A	18A	27A
	Max Input Power	800W	5000W	9000W
	MPPT	17-115Vdc	40-450Vdc	60-450Vdc
	voltage	20V	60V	80V
Max charging current	/	100A	100A	120A Default100A
AC Output	Output Voltage	208/220/230/240VAC
	Voltage Regulation	≤±5%
	Power factor	1
	Frequency Range	Line Mode: Synchronized range, Battery Mode:50/60Hz+0.1%
	Output Power rating	1.2KVA	3.6KVA	6KVA
	Over load Capacity	1min @102%
Battery	Nominal Voltage	12V	24V	48V
	charging Current	2~50A	2~100A	2~120A
Battery protection	Battery over Voltage	16V	30.5V	61V
	Battery under voltage	10.5V	10.5V*N	10.5V*N
	Battery low voltage alarm	11V	10.8V*N	10.8V*N
	Over current protection过	Fuse
Environment	Ambient temperature	-10℃~60℃
	Humidity	20%~95%(Nocondensing)
	Storage temperature	-15℃~60℃
Communication	RS232 Port	5PIN/Pitch2.0mm
	Expansion port	2x13PIN/Pitch2.0mm+1x12PIN/Pitch2.0mm
	Overall size	377269165mm	518342170mm	490394181mm
	Machine weight	4.2KG	7.3KG	9.5KG
