RSM-50 Type 5 Ton Hydraulic Cylinder Lifting Tool Hydraulic Jack

As a Chinese company who focus on producing the durable hydraulic lifting tools for the electric power line workers with the competitive prices, our MARSHINE have been manufacturing the hydraulic jack tools for one decade. And this MARSHINE RSM-50 Type 5 Ton Hydraulic Cylinder Lifting Tool Hydraulic Jack was a hydraulic powered lifting tool which is able to provide the operators with the outstanding 5 ton support to hold the heavy-duty loads or lifting the equipment for the constructions.

The MARSHINE RSM-50 Type 5 Ton Hydraulic Cylinder Lifting Tool Hydraulic Jack with the lifting capacity that up to 5 ton is able to provide the operators with the higher efficiency in lifting, pushing, or positioning the loads where the strength and the stability are essential. And with its compact and lightweight design, makes this tool highly portable, while its robust construction is able to ensures the long service life under the demanding conditions.

Been manufactured with the high-strength alloy steel for the enhanced durability and the reliability, and the compact yet light weight design to ensure its portability and make it ideal for the use in the confined or the spaces that hard to reach, this MARSHINE RSM-50 Type 5 Ton Hydraulic Cylinder Lifting Tool Hydraulic Jack with the high lifting capacity that up to 5 tons is able to help the users deal with the heavy loads, and the oil-painted protective coating is able to ensures the long-term performance even in the harsh construction environments. With the precision hydraulic systems to provide the smooth and controlled lifting with the minimal efforts, this tool is able to effectively improve your team's construction efficiency. And due to its overload protection, this tool can protect the operator's personal safety well.

This MARSHINE RSM-50 Type 5 Ton Hydraulic Cylinder Lifting Tool Hydraulic Jack is suitable for the power line and the utility construction projects, and can be applied to the industrial machinery installation and maintenance operations, or for the heavy equipment lifting, positioning, or alignment tasks as well. It is also perfect for the construction, railway, and the bridge projects that requires for the reliable lifting tools, or the general maintenance, repair, and emergency lifting tasks.

Technical Parameters

Model

Tonnage(T)

Stroke

(mm)

Cylinder area(cm2)

Oil capacity

(cm3)

Height

(mm)

Extend height(mm)

Out diameter(mm)

Weight

(kg)

MARSM-50

6.4

59×41

Series Parameters

Model	Tonnage(T)	Stroke (mm)	Cylinder area(cm2)	Oil capacity (cm3)	Height (mm)	Extend height(mm)	Out diameter(mm)	Weight (kg)
MARSM-50	5	6	6.4	4	33	39	59×41	1
MARSM-100	10	11	14.5	16	43	54	83×56	1.4
MARSM-200	20	11	28.6	31	52	63	102×76	3.1
MARSM-300	30	13	42	55	59	72	118×95	4.5
MARSM-500	50	16	62.1	99	67	83	140×114	6.8
MARSM-750	75	16	102.7	164	80	96	165×139	11.4
MARSM-1000	100	16	126.8	203	86	102	178×152	14.5
MARSM-1500	150	14	198.1	277	100	114	216×191	26.3
