2.0mm Metal Mesh Plate leveling

JZ-60S(T:1.0-6.0mm)

Specialized in Metal Plate Leveling Machines with 20+ Years of Technical Expertise​

Developed through dedicated R&D, JIUZH's leveling machine applies the "Bauschinger Effect" ，sheet metal was repeatedly twisted to make metal fiber gradually consistent, eliminate internal stress, restore and improve the flatness,the precision can reach micron level.The stagger arranged support rollers ensure leveling rollers bearing heavy pressure in balance without bending deformation, keeping the whole equipment have enough rigidity. Upper and lower support roller column & upper and lower leveling roller group making up four-high or six-high layers structure, ensuring stable, efficient and high-quality leveling performance.

Eliminating texture on precision rolled strips: Utilizing φ60mm small roll diameters, it can closely adhere to the rolling lines and local warps of 0.1-3mm stainless steel strips (such as 304, 316L strips), combined with precise servo-controlled pressure (pressure accuracy ±0.008MPa), eliminating longitudinal stress and edge waves. After leveling, the flatness error is ≤0.1mm/m, meeting the cutting and stamping requirements for precision hardware and medical device accessories;

Protecting the surface from wear and maintaining smoothness: The roll system's synchronization error is <0.005mm, preventing scratches or indentations on the surface of the stainless steel strip. After leveling, the roughness of the strip Ra is ≤0.2μm. It can enter the subsequent welding and bending processes without polishing, reducing processing losses;

Small Roller Precise Leveler for Stainless Steel Strips (Manual Model)

The Small Roller Precise Leveler for Stainless Steel Strips is designed with advanced technology specifically for leveling stainless steel strips. It effectively removes surface defects such as waviness, warping, and unevenness, providing a smoother surface that meets the high-precision demands of metalworking. As a Manual Plate Leveling Machine, it is easy to operate and can be adjusted to handle different thicknesses and materials of stainless steel strips, making it perfect for various leveling needs in stainless steel production lines.

The machine features a Thin Sheet Roller Leveller roller system that ensures even pressure distribution during the leveling process, preventing damage to the metal strip. The precise control system ensures that the stainless steel strip retains its smooth, defect-free surface after leveling, making it suitable for subsequent processing steps such as cutting, stamping, and welding. As a Thin Sheet Flattener, this equipment delivers unparalleled performance in the leveling of stainless steel strips, helping users improve production efficiency and reduce material waste.

Additionally, this leveling machine is highly efficient, capable of completing high-precision leveling tasks in a short period of time, significantly boosting productivity. Its performance as a sheet leveling machine makes it an ideal choice for stainless steel strip manufacturers and metalworking factories looking to enhance their production capabilities.
