Q245, Q345, 15Mo, 20Mo, 12CrMo Submerged-arc Welded Steel Pipe for High Temperature and High Pressure
Material
Q245, Q345, 15Mo, 20Mo, and 12CrMo are high-strength low-alloy and alloy structural steels designed for demanding high-temperature and high-pressure applications. These grades offer a balance of tensile strength, toughness, and thermal stability, making them ideal for manufacturing submerged-arc welded (SAW) steel pipes used in boilers, pressure vessels, and pipeline systems operating under severe service conditions.
Specification
-
Outer Diameter (OD): 406 mm – 1620 mm (customizable)
-
Wall Thickness: 8 mm – 60 mm (customizable)
-
Length: 6 m – 12 m (fixed or random length; longer lengths available by request)
-
Manufacturing Process: Longitudinal or spiral submerged-arc welding (LSAW or SSAW)
-
Standards: GB/T 9711, GB/T 8163, GB/T 8162, ASME SA-106, ASTM A335 (where applicable)
-
Heat Treatment: Normalizing, Quenching + Tempering (as required)
-
End Finish: Plain end, bevelled end, or grooved end; protective caps optional
Key Features
-
High-Temperature Strength – Maintains mechanical integrity at elevated temperatures.
-
High-Pressure Resistance – Suitable for steam, gas, and liquid transport under high internal pressures.
-
Excellent Weldability – Submerged-arc welding ensures deep penetration and uniform weld seams.
-
Corrosion and Oxidation Resistance – Alloy elements such as molybdenum and chromium improve durability.
-
Dimensional Accuracy – Precision forming and controlled heat treatment guarantee tight tolerances.
-
Customizable Sizes & Lengths – Adaptable to different engineering and installation requirements.
Chemical Composition (Typical Values, %)
| Steel Grade | C | Si | Mn | P (max) | S (max) | Cr | Mo | V | Ni |
|---|---|---|---|---|---|---|---|---|---|
| Q245 | ≤0.20 | ≤0.35 | 0.40-0.70 | 0.030 | 0.030 | — | — | — | — |
| Q345 | ≤0.20 | ≤0.50 | 1.00-1.60 | 0.030 | 0.030 | — | — | — | ≤0.30 |
| 15Mo | ≤0.15 | ≤0.35 | 0.40-0.80 | 0.025 | 0.025 | — | 0.25-0.35 | — | — |
| 20Mo | ≤0.20 | ≤0.35 | 0.40-0.80 | 0.025 | 0.025 | — | 0.25-0.35 | — | — |
| 12CrMo | ≤0.15 | ≤0.50 | 0.40-0.80 | 0.025 | 0.025 | 0.90-1.20 | 0.25-0.35 | — | — |
Mechanical Properties
| Steel Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Impact Toughness (J) |
|---|---|---|---|---|
| Q245 | 370-500 | ≥245 | ≥25 | ≥27 |
| Q345 | 470-630 | ≥345 | ≥21 | ≥27 |
| 15Mo | 410-550 | ≥245 | ≥22 | ≥27 |
| 20Mo | 410-560 | ≥275 | ≥20 | ≥27 |
| 12CrMo | 470-640 | ≥295 | ≥20 | ≥27 |
Steel Grade
-
Carbon Structural Steel: Q245
-
Low-Alloy High-Strength Steel: Q345
-
Alloy Steels for Pressure Vessels and Boilers: 15Mo, 20Mo, 12CrMo
Application
-
Power Generation: Boiler tubes, steam pipelines, superheater coils.
-
Petrochemical Industry: Refinery piping, high-pressure heat exchangers.
-
Chemical Processing: Reaction vessels, process piping for hot corrosive fluids.
-
Oil & Gas: High-pressure transmission lines for oil, gas, and steam.
-
Industrial Boilers: Economizer, reheater, and header piping.
Possible Alternative Grades
-
ASTM A335 P1, P2, P11 (for high-temperature service)
-
ASTM A106 Grade B/C (for high-pressure applications)
-
ASTM A671, A672 (welded pipes for high-temperature service)
-
EN 10216-2 16Mo3, 13CrMo4-5
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
