300 Aluminum Continuous Extrusion Machine

As a compact and high-efficiency Conform Continuous Extruder, the 300 Aluminum Continuous Extrusion Machine is a high-performance extrusion system designed for the efficient production of solid and hollow aluminum products. This professional Rod-To-Profile Extrusion Equipment utilizes advanced Friction-Driven Extrusion System and serves as core processing unit for lightweight Non-Ferrous Metal Extrusion Line. This machine utilizes radial direction continuous extrusion technology with a single wheel and single groove, making it ideal for processing both pure aluminum and aluminum alloys. The extrusion process is optimized to ensure consistent quality, high productivity, and minimal material waste. With a nominal extrusion wheel diameter of 300mm, this machine is capable of handling a wide range of aluminum rod sizes, including Ø9.5mm and Ø12mm, allowing for flexibility in manufacturing different types of aluminum profiles.

I. Introduction

Extrusion mode: Radial direction continuous extrusion by single wheel and single groove

Application: Solid and hollow aluminum.

Raw material: Ø9.5mm Aluminum rod

II. Main Technical Specifications

Extrusion wheel nominal diameter       300mm

Main motor power                              90kw

Installed power                                   110kw

Extrusion machine speed                     22.5 m/rpm

Types of materials                               Pure aluminum,aluminum alloy

Rod diameter                                      F9.5/12

Product scope of section                      5-150mm²

Product maximum width                      Flat wire,30 mm flat tube,pipe diameter 20 mm

Average productivity                            230kg/h

Material overflow rate                          0
