OBD male (24V) and OBD female (Kia) connectors to Molex 20P and BMW 10P Y-wires
2 month ago
Shenzhen Fubang Wire harness Co.,Ltd
13 month
Product details
In specialized automotive diagnostic and customization scenarios, standard OBD adapters often fall short of meeting the unique port requirements of specific vehicle brands and advanced electronic systems. The OBD Male (24V) & OBD Female (Kia) to Molex 20P & BMW 10P Y-Wires emerge as a tailored solution, addressing the connectivity gap between brand-specific OBD interfaces, high-voltage 24V systems, and specialized Molex/BMW ports. This Y-shaped wiring assembly is a game-changer for technicians working on Kia vehicles, BMW models, and 24V commercial or heavy-duty vehicles, as well as those needing to interface with Molex-based electronic modules.
At its core, this Y-wire setup solves two critical compatibility challenges simultaneously. On one branch, the 24V OBD male connector caters to vehicles with 24V electrical systems—common in commercial trucks, buses, and some heavy-duty equipment—ensuring safe and stable signal transmission without voltage mismatch risks. On the other branch, the OBD female connector designed for Kia perfectly mates with Kia’s proprietary OBD ports, eliminating the frustration of loose fits or unrecognized connections that often occur with generic adapters when diagnosing Kia’s engine control units (ECUs) or infotainment systems.
The dual output ends—Molex 20P and BMW 10P—extend the wire’s utility further. The Molex 20P connector is ideal for linking to aftermarket electronic modules, such as custom gauges, performance tuners, or data loggers that use Molex’s industry-standard 20-pin interface. Meanwhile, the BMW 10P connector is engineered to fit BMW’s specialized diagnostic and control ports, a must for technicians servicing BMW’s advanced driver assistance systems (ADAS) or accessing deep ECU data that standard OBD tools can’t reach. The Y-wire design allows for simultaneous connection to two different devices, saving time and reducing the need for multiple wiring setups.
Durability and signal integrity are prioritized in the wire’s construction. The cables use oxygen-free copper conductors, which minimize signal loss and ensure efficient current transfer—critical for accurate diagnostic readings and reliable communication between devices. The outer sheath is made of abrasion-resistant PVC, protecting the internal wires from oil, grease, and mechanical damage in garage or workshop environments. Each connector features precision-machined pins with gold plating, enhancing corrosion resistance and extending the wire’s lifespan even with frequent plugging and unplugging.
For end-users, the benefits are tangible. Automotive technicians can streamline diagnostic workflows: a single Y-wire replaces multiple adapters when switching between Kia vehicles, 24V equipment, BMW models, and Molex-based modules. Enthusiasts modifying their vehicles also benefit, as the wire simplifies integrating aftermarket parts with the vehicle’s existing electrical system. Additionally, the plug-and-play design requires no soldering or complex wiring, making it accessible even for those with basic technical knowledge—simply connect the appropriate OBD end to the vehicle and the desired output connector to the target device, and communication is established.
In summary, the OBD Male (24V) & OBD Female (Kia) to Molex 20P & BMW 10P Y-Wires redefine versatility in automotive connectivity. By combining brand-specific, voltage-specific, and industry-standard connectors into one assembly, it eliminates compatibility headaches, boosts efficiency, and ensures reliable performance. For anyone working with Kia, BMW, 24V vehicles, or Molex modules, this Y-wire is not just an accessory—it’s an essential tool that bridges specialized needs with seamless functionality.
