AC vacuum pump refrigerant VALUE FY-4C-N single stage vacuum pump price1
3 year ago
2.Copper wire motor,long service life.
3.Big sight glass for monitoring oil level,prevent oil lack.
4.The overall design of pump and motor is more portable.
5.Low maintenance cost
|
Item
|
Single stage vacuum pump
|
|
|
|
|
||||
|
Model
|
FY-1C-N
|
FY-1.5C-N
|
FY-2C-N
|
FY-3C-N
|
FY-4C-N
|
||||
|
Rated voltage
|
220V~/50Hz
|
220V~/50Hz
|
220V~/50Hz
|
220V~/50Hz
|
220V~/50Hz
|
||||
|
Pumping rate
|
3.6m3/h
|
5.4m3/h
|
7.2m3/h
|
10.8m3/h
|
14.4m3/h
|
||||
|
Ultimate pressure
|
2Pa
|
2Pa
|
2Pa
|
2Pa
|
2Pa
|
||||
|
Motor power
|
150w
|
180w
|
250w
|
370w
|
550w
|
||||
|
Oil capacity
|
250ml
|
250ml
|
250ml
|
415ml
|
660ml
|
||||
|
Dimension(mm)
|
290*124*224
|
290*124*224
|
318*124*234
|
338*138*244
|
395*145*257
|
||||
|
Weight
|
6.5kg
|
7.1kg
|
8.1kg
|
10.0kg
|
14.7kg
|
||||
|
Inlet port
|
7/16"-20UNF
|
7/16"-20UNF
|
7/16"-20UNF
|
7/16"-20&5/8-18UNF
|
7/16"-20&5/8-18UNF
|
||||
