Product details

PVC pressure pipe is mainly made of sanitary grade polyvinyl chloride (PVC) resin, with the addition of appropriate stabilizers, lubricants, fillers, color enhancers, etc. They are extruded by plastic extruders and injection molded by injection molding machines. Through cooling, curing, shaping, inspection, packaging and other processes,

the production of pipes and fittings is completed.

Compared with traditional pipelines, Upvc water supply pipe have the advantages of light weight, corrosion resistance, low water flow resistance, energy saving, quick installation, and low cost. They have been widely promoted and applied, and the benefits are significant.

Two types of pvc-u water supply pipe for water supply are available:one is joined by solvent cement,and the other by rubber ring.

Outside Diameter(mm)	0.63MPa	0.8MPa	1.0MPa	1.25MPa	1.6MPa	2.0MPa
Outside Diameter(mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)
20					1.5	2.0
25				1.5	2.0
32			1.6	2.0	2.4
40			2.0	2.4
50		2.0	2.4	3.0
63	2.0	2.5	3.0	3.8
75	2.3	2.9	3.6	4.5
90	2.8	3.5	4.3	5.4
110	2.7	3.4	4.2	5.3
125	3.1	3.9	4.8	6.0
140	3.5	4.3	5.4	6.7
160	4.0	4.9	6.2	7.7
180	4.4	5.5	6.9	8.6
200	4.9	6.2	7.7	9.6
225	5.5	6.9	8.6	10.8
250	6.2	7.7	9.6	11.9
280	6.9	8.6	10.7	13.4
315	7.7	9.7	12.1	15.0
355	8.7	10.9	13.6	16.9
400	9.8	12.3	15.3

Outside Diameter(mm)	0.63MPa	0.8MPa	1.0MPa	1.25MPa
Outside Diameter(mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)
63	2.0	2.5	3.0	3.8
75	2.3	2.9	3.6	4.5
90	2.8	3.5	4.3	5.4
110	2.7	3.4	4.2	5.3
125	3.1	3.9	4.8	6.0
140	3.5	4.3	5.4	6.7
160	4.0	4.9	6.2	7.7
180	4.4	5.5	6.9	8.6
200	4.9	6.2	7.7	9.6
225	5.5	6.9	8.6	10.8
250	6.2	7.7	9.6	11.9
280	6.9	8.6	10.7	13.4
315	7.7	9.7	12.1	15.0
355	8.7	10.9	13.6	16.9
400	9.8	12.3	15.3
450	11.0	13.8	17.2
500	12.3	15.3	19.1
630	15.4	19.3	24.1
710	17.4	21.8	27.2
