Product details

Double Circuit Steel Metal Hydraulic Punching Machines

MARSHINE is committed to research and develop the excellent quality hydraulic tools for the electrical construction, the power-line work and the industrial application. Our MARSHINE philosophy is rugged, precision and provides great value without the sacrificing performance. This Double Circuit Steel Metal Hydraulic Punching Machines have a 50-Ton working pressure and designed for the demanding metal punching applications with the dependable dual-oil-circuit design.

This MARSHINE CH-80B Hydraulic Hole Punch can produce a working pressure of 50 tons, which making it ideal for punching applications that require high pressure.

It has a throat depth of 85mm for penetration into the thicker structural profiles.

It can stamp the iron plates with a maximum thickness of 25 mm.

It permits punching of the copper and the aluminium busbars with thickness of up to 22 mm.

The module can accept punch sizes of 16 mm, 18 mm, 22 mm, and 25 mm.

It comes with a flat pedestal shape for the better stability while you are working.

This hydraulic punching press is ideal for the structural steel fabricators that routinely punch the angle steel or the H-beam members.

The MARSHINE Hydraulic Hole Puncher can be used during utility or power-line construction for punching holes in copper or aluminium busbars within switch gear or grounding systems.

It is perfect for the substation panel assembly shops, where you have to make the multiple accurate hole punches in the iron plates.

This is perfect for maintenance personnel who need a powerful and portable punching machine, which can modify the existing metal structures or the adding ports.

Product Parameter

Model	CH-80B
Working Pressure(T)	50
Dimension(mm)	255130300
Stroke(mm)	25
Die Configuration(mm)	ф16,ф18,ф22,ф25
Throat Depth(mm)	85
Weight(KG)	60
Size(cm)	372248

Heavy Duty Hydraulic Punch With Electric Hydr
