Product details

PVC-UH Water and Drainage Pipe (PVC-UH) is a kind of pipe for sewage discharge and drainage which is made of hard polyvinyl chloride(PVC) mixed with standard requirements, extruded and has an integrated steel skeleton sealing ring socket structure. Adopts

efficient and excellentheat stabilizer and advanced production technology to ensure the quality of pipes.

PVC-UH sewage pipes is widely used in conveying domestic sewage and specific industrial wastewater.

PVC-Uh Drainage Pressure Pipes Product Description

Outside Diameter(mm)	SDR51 0.32MPa（SN2)	SDR41 0.4MPa（SN4)	SDR34 0.5MPa（SN8)	SDR28 0.6MPa（SN12.5)	SDR26 0.63MPa（SN16)
Outside Diameter(mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)
110		3.2	3.2	4.0	4.2
125		3.2	3.7	4.5	4.8
160	3.2	4.0	4.7	5.8	6.2
200	3.9	4.9	5.9	7.2	7.7
250	4.9	6.2	7.3	9.0	9.6
315	6.2	7.7	9.2	11.3	12.1
355	7.0	8.7	10.4	12.7	13.6
400	7.9	9.8	11.7	14.3	15.3
450	8.8	11.0	13.2	16.1	17.2
500	9.8	12.3	14.6	17.9	19.1
630	12.3	15.4	18.4	22.5	24.1
710	13.9	17.4	20.9	25.4	27.2
800	15.7	19.6	23.5	28.6	30.6
900	17.6	22.0	26.5	32.2	34.4
1000	19.6	24.5	29.5	35.8	38.2
1200	23.5	29.4	35.3	42.9	45.9
1400	27.4	34.3	41.2
1600	31.3	39.2

Pvc-uh Pipes for Low-Pressure Sewage and Drainage

PVC Sewer Pipe Feature highlights

High-performance rigid PVC-UH pipes designed for pressure discharge and drainage, featuring high strength, corrosion resistance, UV protection, and a long service life. Suitable for municipal, building, industrial, and agricultural applications. Customizable sizes and colors with easy installation. Complies with SZDB/Z 239-2017 and T/CECS 10110-2020 standards.

PVC drainage Pipe Application

Municipal water supply and drainage system

Building water supply and drainage system

Industrial pipeline

Agricultural irrigation system
