The relationship between cylinder liner and piston ring

Inside the engine, the combination of cylinder liner and piston ring is a model of precision tribology - a tight fit to prevent air leakage and reduce friction and loss.

The tacit understanding of this "golden pair" is determined by two scientific principles:

Lubricating film: a "cushion" of friction

1. Principle: When the piston moves at high speed, the oil forms an oil film several microns thick between the cylinder liner and the piston ring, which is like the "water cushion" between the skating shoes and the ice surface, converting the direct friction into liquid shear.

2. Key indicators: oil film thickness should be maintained at 1.5-3μm, too thin leads to dry grinding (boundary friction), too thick increases resistance (viscosity loss).

Surface texture: "miniature water channel" for oil storage and flow diversion

1. Inner wall of cylinder liner: laser honing to form 25° cross mesh, which not only stores lubricating oil, but also guides oil evenly distribution.

2. Piston ring: diamond-like (DLC) coating surface shows nanoscale pits, friction coefficient is as low as 0.08, which reduces wear by 30% compared with traditional chrome-plated rings.
