Product details

Product Name: High - Speed Pneumatic Parallel Three - Claw Gripper

Keywords: Fast - Acting Gripper for Electronics Assembly, Precise Gripper for Small Parts, Efficient Gripper for Automated Production

Product Introduction:

Introducing the High - Speed Pneumatic Parallel Three - Claw Gripper, model FY - JGZ80 - 1 - AS, a cutting - edge solution engineered to boost efficiency in electronics assembly, small - part handling, and automated production. Weighing just 0.96kg, it boasts a compact and lightweight design, enabling easy integration into robotic systems.

Operating within an air pressure range of 3 - 8 bar, it delivers a gripping force of 1350N when closed, with a minimum spring force of 350N, ensuring secure handling of workpieces. With a stroke of 16mm (2×8mm) and an exceptional repeat accuracy of 0.01mm, it guarantees precise and consistent manipulation of parts.

In electronics assembly, this fast - acting gripper excels with its ultra - fast closing/opening time (0.05/0.03 sec respectively), facilitating swift grasping and placement of tiny electronic components to streamline the assembly process. For small - part handling, the precise gripper enables accurate transfer of small items, optimizing workflow in industries dealing with miniature parts.

In automated production lines, the efficient gripping action and rapid operation make it ideal for various tasks, from component sorting to product packaging. It has a max length attach of 90mm and a fitting size of M5 - 6H, suitable for various setups. Air consumption per cycle is 60cm³, ensuring efficient use of compressed air.

Operating without the need for lubrication, it simplifies maintenance. Safety protection rated IP40 as per IEC60529 standard ensures safe operation in industrial environments. All data is measured at 6 bar air pressure, and it maintains performance after 100 consecutive strokes to end positions. Overall, this pneumatic three - claw gripper is a vital asset for optimizing industrial operations, especially in sectors requiring speed and precision
