ACE, ACG, ACF Series Screw Pumps

2 week ago

2 0 

Ningbo Hengnuo Hydraulic Drive Co.,Ltd

4 year

Product details

ACE Series Screw Pumps

• Flow Range: 15 to 160 liters per minute (at 50Hz).

• Application Areas:

• Lubrication: Lubricating diesel engines, gears, gas/steam turbines, hydraulic turbines, paper machines, etc.

• Circulation and Filtration: Cooling and filtration for large machinery and hydraulic systems.

• Fuel Supply: Providing fuel supply for diesel engines.

• Transfer: Transferring fluids on ships, in oil plants, refineries, and tank farms.

• Media Adaptability: Suitable for various fluid media, including lubricating oil, fuel oil, vegetable oil, hydraulic oil, and other hydraulic fluids, ethylene glycol, polymers, emulsions, and any non-corrosive fluids with certain lubricating properties.

• Features: ACE pumps can provide approval certificates from major classification societies, such as ABS, BV, CCS, DNV, GL, KR, LRS, NK, RINA, RS.

ACG Series Screw Pumps

• Flow Range: 65 to 850 liters per minute (at 50Hz).

• Application Areas:

• Lubrication: Lubricating diesel engines, gears, gas/steam turbines, hydraulic turbines, paper machines, etc.

• Circulation and Filtration: Cooling and filtration for large machinery and hydraulic systems.

• Fuel Systems: Used for supply and circulation in fuel systems.

• Transfer: Transferring fluids on ships, in oil plants, refineries, and tank farms.

• Media Adaptability: Similar to the ACE series, suitable for various fluid media, including lubricating oil, fuel oil, vegetable oil, hydraulic oil, etc.

• Features:

• Maximum differential pressure up to 16 bar.

• Robust pump body design, capable of adapting to various harsh industrial environments.

• Equipped with pressure regulation and protection devices to ensure safe operation of the pump.

ACF Series Screw Pumps

• Flow Range: 300 to 3000 liters per minute.

• Application Areas:

• Lubrication: Serving as the main lubrication pump and pre-lubrication pump for diesel engines, gears, gas/steam turbines, hydraulic turbines, paper machines, etc.

• Circulation and Filtration: Cooling and filtration for large machinery and hydraulic systems.

• Transfer and Pressurization: Pumping transformer insulating oil into transformers, pressurizing the pressure chambers of hydraulic presses, transferring fluids on ships, in oil plants, refineries, and tank farms.

• Media Adaptability: Also suitable for various fluid media, including lubricating oil, fuel oil, vegetable oil, hydraulic oil, etc.

• Features:

• Self-priming design, with strong self-priming capability.

• Uniform and continuous flow, low vibration, low noise, and almost no pulsation.

• Robust structure, easy installation, and simple maintenance.

• High heat resistance, with heating or cooling structures available according to the needs of the conveyed medium.
