Model
|
SUN-7K-G02P1-EU-AM2
|
SUN-7.5K-G02P1-EU-AM2
|
SUN-8K-G02P1-EU-AM2
|
|||
|
Max. PV Input Power (kW)
|
10.5
|
11.3
|
12
|
|||
|
Max. PV Input Voltage (V)
|
550
|
|
|
|||
|
Start-up Voltage (V)
|
80
|
|
|
|||
|
MPPT Voltage Range (V)
|
70-500
|
|
|
|||
|
Rated PV Input Voltage (V)
|
360
|
|
|
|||
|
AC Output Side
|
|
|
|
|||
|
Rated AC Output Active Power (kW)
|
7
|
7
|
8
|
|||
|
Max. AC Output Apparent Power (kVA)
|
7.7
|
8.25
|
8.8
|
|||
|
Rated AC Output Current (A)
|
31.9/30.5
|
34.1/32.7
|
36.4/34.8
|
|||
|
Max. AC Output Current (A)
|
35/33.5
|
37.5/35.9
|
40/38.3
|
|||
|
Rated Output Voltage/Range (V)
|
220/230 0.85Un-1.1Un
|
|
|
|||
|
Grid Connection Form
|
L/N/PE
|
|
|
|||
|
Rated Output Grid Frequency/Range(Hz)
|
50/45-55, 60/55-65
|
|
|
|||
|
Efficiency
|
|
|
|
|||
|
Max. Efficiency
|
97.7%
|
|
|
|||
|
Euro Efficiency
|
97.2%
|
|
|
|||
|
MPPT Efficiency
|
>99%
|
|
|
|||
|
Interface
|
|
|
|
|||
|
Communication Interface
|
RS485/RS232
|
|
|
|||
|
Monitor Mode
|
GPRS/WIFI/Bluetooth/4G/LAN(optional)
|
|
|
|||
|
General Data
|
|
|
|
|||
|
Operating Temperature Range (°C)
|
-25 to +60℃, >45℃ Derating
|
|
|
|||
|
Permissible Altitude (m)
|
3000m
|
|
|
|||
|
Noise (dB)
|
≤35
|
|
|
|||
|
Ingress Protection(IP) Rating
|
IP 65
|
|
|
|||
|
Cabinet Size (WxHxD mm)
|
330×310×208.5 (Excluding Connectors and Brackets)
|
|
|
|||
|
Weight (kg)
|
12.1
|
|
|
|||
|
Warranty
|
5 Years
|
|
|
|||
|
Type of Cooling
|
Natural Cooli
|
|
|
|||
|
Grid Regulation
|
IEC 61727, IEC 62116, EN 50549, NRS 097, RD 140, UNE 217002, G99
|
|
|
|||
|
Safety EMC/Standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
|
|
|
|||
