Energy Storage System 25.6v Lithium Battery System Wall-mounted Solar Power System Hybrid Grid Connection System1
7 month ago
|
Product Name
|
BA-ESS-14.336KWH
|
|
Cell
|
3.2V/280Ah
LiFeCoPO4 3.2V/280Ah |
|
Array mode
|
16S1P
|
|
Rated capacity
|
280Ah
|
|
Minimum capacity
|
≥266Ah
|
|
Capacity
|
14.366KWh
|
|
Operating voltage
|
40-58.4V
|
|
Rated voltage
|
51.2V
|
|
Resistance
|
IR≤0.21mΩ
|
|
Charge voltage
|
58.4V
|
|
Discharge cut-off voltage
|
40V
|
|
Standard charging current
|
100A
|
|
Standard discharging current
|
100A
|
|
Max continuous discharge current
|
150A
|
|
Communication port
|
RS485/CAN/232
|
|
Light
|
ALM / RUN / SOC
|
|
Cycle life
|
6000 cycles
(0.5C charge ， 0.5 discharge, capacity) |
|
Operating temperature
|
Charging: 0℃～55℃; Discharging: -20℃～55℃;
|
|
Storage temperature
|
1 month： -20℃～45℃；
1 year：0℃～35℃； 1 year：0℃～35℃； |
|
Weight（Kg)
|
120±1Kg
|
|
Relative humidity
|
65±20%
|
