5 Gallon Bottle Cap Making Mold Customized Fuhong FHG 240 Ton Plastic Injection Molding Machine1

[FHG22000]

Solutions by Industry

Key Features

1. Stable Clamping System for consistent mold locking, fewer flashes, and reliable continuous production
2. Accurate Injection Performance for smooth plasticizing, precise material control, and stable shot repeatability
3. Energy-Saving Operation with servo drive that adjusts output to actual demand, reducing power consumption and operating costs
4. User-Friendly Control System for easier operation, parameter setting, fault checking, and production monitoring
5. Flexible Customization with configuration suggestions based on your product size, mold structure, material type, and output target

Why Work with FUHONG

1. Over 20 years of experience in injection molding machinery and mold manufacturing
2. Complete plastic processing solutions including machines, molds, auxiliary equipment, and production line matching
3. Global supply and support including machine selection, configuration advice, installation guidance, operation training, and after-sales service
4. Practical, durable, and cost-effective equipment designed for long-term production value

Technical Specifications

ITEM		UNIT	FHG22000
Injection Unit	Screw Diameter	mm	130	140	150	160
	Screw L/D Ratio	L/D	25	23	21	20
	Shot Volume(Theoretical)	cm3	9950	11540	13247	15072
	Injection Weight(PS)	g	9054	10501	12055	13716
	Injection Pressure	Mpa	199	171	149	131
	Injection Rate	g/s	1172	1360	1560	1776
	Screw Speed	r/min	0-100
Clamping Unit	Clamping Force	KN	22000
	Toggle Stroke	mm	1800
	Max. Mould Height	mm	1700
	Min. Mould Height	mm	650
	Space Between Tie-Bars	mm	1800×1600
	Ejector Force	KN	450
	Ejector Stroke	mm	450
Others	Pump Motor Power	KW	56+56+56
	Heater Power	KW	110.7
	Max. Pump Pressure	Mpa	16
	Machine Dimension(L*W*H)	m	16.80×3.80×4.30
	Machine Weight	Ton	130
	Oil Tank Capacity	L	3700
