motor for seeder

3 month ago

17 0 

Jinan Keya Electron Science And Technology Co., Ltd.

7 year

Product details

2V 50W high precision integrated seeder motor

FAQ

1.Is it possible to extend the cable length, or is it possible to request a version with a custom cable?

It can be customized.

2.Is there an option for firmware update or remote parameter configuration (for example, via USB-CAN adapter)?

Yes

3.Is the integrated controller in SG-6010D already configured by default (such as CAN ID, baud rate, control mode)?

Or do we need to set it through software or serial commands (as required by other manufacturers)?

It is already set by default. If you need to modify it, do it through the software.

4.Do you offer output gearboxes with higher rotational speeds?

Yes, customization is available.

5.Is the USB to CAN adapter (for the Keya Tool software) included with the motor, or do you need to purchase it separately?

CAN card, type C port data cable, purchased separately, total 25 USD

6.What are the purposes of these two cables? Are all functions (power supply + CAN communication) included in a 4-pin Deutsch connector?

The motor has a positive and negative power supply connected by a 2-wire cable, and CANH and CANL are also connected by a 2-wire cable, which are finally connected to a Deutsch connector.

7.It is impossible to change "can msg" from the standard format to the extended format. Is there any command that can achieve this?

It cannot be modified. Even with a CAN card, it cannot be modified.
