MICRO SATA RECEP R/A,DIP TYPE 90°

2 month ago

3 0 

5 year

Product details

Huizhou Antenk Electronics Co., Ltd. (IATF16949, ISO9001, ISO14001 certified) presents the Micro SATA Receptacle, Right Angle DIP Type. This 90° angled surface mount / through-hole hybrid connector is designed for high-speed serial data transmission in compact storage devices, supporting SATA 2.0 (3Gbps) and SATA 3.0 (6Gbps) standards. The receptacle features a low-profile, right-angle housing molded from high-temperature UL94 V-0 rated LCP or PBT, with stamped phosphor bronze contacts selectively gold plated on mating areas and tin plated on solder tails. Key specifications: current rating 1.5A per contact, contact resistance <30mΩ, insulation resistance >1000MΩ, dielectric strength 500V AC, operating temperature -40°C to +85°C. The robust metal shell provides EMI shielding and mechanical retention.

Applications include solid-state drives (SSD), notebook computers, ultrabooks, external portable hard drives, and embedded storage modules. Usage: solder the DIP tails through PCB holes using wave or reflow soldering (peak 260°C). The right-angle orientation allows edge‑mount placement, saving board space. Precautions: avoid excessive mating force (max 30N), ensure proper alignment before insertion, do not exceed 1.5A per contact. Advantages over competitors: Antenk’s micro SATA receptacle uses a reinforced metal latch design rated for 5,000 mating cycles – 2x industry average. Coplanarity is controlled within 0.08mm to eliminate soldering defects. Low MOQs (1,000 units) with no tooling fees for standard configurations.

Production process: in-house mold design → injection molding (10 Japan/Taiwan machines) → high-speed stamping (9 presses) → selective gold/tin plating → automated assembly → 100% coplanarity & pin position inspection → contact resistance & insulation tests → 48h salt spray test → final QC with lot traceability. Free samples, 2D/3D CAD drawings, and 24/7 technical support available. Contact Antenk for competitive pricing and fast delivery.

FAQ

Q: Are you trading company or manufacturer?

A: We are professional manufacturer specialized in connector and cables. And we export e our products with our clients directly.

Q: Can you do OEM and ODM?

A: Yes, OEM and ODM are both acceptable. The material, color, style can customize, the basic quantity we will advise after we discuss.

we can support ODM and OEM service here, we have strong R&D team in Atkconn group.

Q: How many different types of products your company manufactures?

A: Now we have more than 10,000 products. We have a strong advantage of OEM, just give us the actual products or your idea that you want, we will manufacture for you.

Q: What’s your MOQ?

A: If we have the products in stock, it will be no MOQ. If we need to produce, we can discuss the MOQ according to customer’s exact situation.
