ISO 4427 PE pipe SDR11

2 month ago

14 0 

10 month

Product details

Advanced HDPE Solutions for Sustainable Urban Infrastructure

Elevate your municipal water distribution network with premium-grade Municipal PE water pipe systems engineered for durability, efficiency, and long-term performance. Designed specifically for modern urban and suburban water supply networks, these high-density polyethylene (HDPE) pipes offer a robust, corrosion-free alternative to traditional materials like cast iron or concrete. Our Municipal Water Distribution Pipe solutions are ideal for potable water conveyance in public infrastructure projects, ensuring safe, reliable, and leak-resistant fluid transport across diverse terrain and climate conditions.

PE pipe product specifications

Outside	0.6MPa	0.8MPa	1.0MPa	1.25MPa	1.6MPa	2.0MPa
Diameter	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)	Thickness (mm)
Dn(mm)
20				2	2.3	2.3
25					2.3	3
32			2.3	2.4	3	3.6
40			2.4	3	3.7	4.5
50		2.4	3	3.7	4.6	5.6
63	2.5	3	3.8	4.7	5.8	7.1
75	2.9	3.6	4.5	5.6	6.8	8.4
90	3.5	4.3	5.4	6.7	8.2	10.1
110	4.2	5.3	6.6	8.1	10	12.3
125	4.8	6	7.4	9.2	11.4	14
140	5.4	6.7	8.3	10.3	12.7	15.7
160	6.2	7.7	9.5	11.8	14.6	17.9
180	6.9	8.6	10.7	13.3	16.4	20.1
200	7.7	9.6	11.9	14.7	18.2	22.4
225	8.6	10.8	13.4	16.6	20.5	25.2
250	9.6	11.9	14.8	18.4	22.7	27.9
280	10.7	13.4	16.6	20.6	25.4	31.3
315	12.1	15	18.7	23.2	28.6	35.2
355	13.6	16.9	21.1	26.1	32.2	39.7
400	15.3	19.1	23.7	29.4	36.3	44.7
450	17.2	21.5	26.7	33.1	40.9	50.3
500	19.1	23.9	29.7	36.8	45.4	55.8
560	21.4	26.7	33.2	41.2	50.8	62.5
630	24.1	30	37.4	46.3	57.2	70.3
710	27.2	33.9	42.1	52.2	64.5	79.3
800	30.6	38.1	47.4	58.8	72.6	89.3
900	34.4	42.9	53.3	66.2	81.7
1000	38.2	47.7	59.3	72.5	90.2
1200	45.9	57.2	67.9	88.2

Frequently Asked Questions:

What makes Municipal PE Water Supply Pipe superior to traditional piping materials?

HDPE offers superior longevity, immunity to corrosion, and enhanced flexibility. It resists scaling, pitting, and biofilm formation—common issues in metal pipes—and requires significantly less maintenance over time.

Can these pipes handle high-pressure applications?

Yes, our HDPE Water Supply Pipes are rated for pressures up to 16 bar (232 psi), making them suitable for primary distribution mains and elevated storage systems.

Are they safe for potable water use?

Absolutely. All materials comply with NSF/ANSI 61 and EU Drinking Water Directive standards, ensuring no harmful leaching into the water supply.

How do I connect the pipes?

We recommend electrofusion or butt fusion techniques using certified fittings and tools. These methods create permanent, leak-tight joints that exceed the strength of the pipe itself.

Do I need special tools for installation?

Standard fusion equipment is required for joining. However, due to their lightweight nature, HDPE pipes can be handled and installed with minimal heavy machinery, reducing site logistics complexity.
