Coin Cel Holders FOR CR2032 SMT With Boss

2 month ago

7 0 

5 year

Product details

Huizhou Antenk Electronics Co., Ltd. (IATF16949, ISO9001, ISO14001 certified) presents the Coin Cell Holder for CR2032 SMT. This surface mount holder is specifically designed for 20mm diameter CR2032 lithium batteries, providing a reliable power connection for compact electronic devices. The housing is molded from high temperature LCP Liquid Crystal Polymer rated UL94 V-0, with a heat deflection temperature of 280 degrees Celsius, enabling reflow soldering without warpage. Contacts are stamped from beryllium copper with selective gold plating of 0.4 microns on the contact tips, ensuring low contact resistance below 25 milliohms. Key specifications include current rating of 200mA continuous, retention force of 70 to 100 grams, low profile height of 2.5mm above PCB, and operating temperature range from -40 to +125 degrees Celsius. The holder features a polarity key and provides audible click feedback when the battery is fully seated. RoHS and REACH compliant, UL recognized under E472792.

Applications include real time clock backup, IoT sensors, medical devices, smart watches, fitness trackers, key fobs, and portable medical monitors. Usage method: the holder is supplied on tape and reel for automatic pick and place. Solder the two SMT pads using standard reflow soldering with peak 260 degrees Celsius and stencil thickness of 0.12mm. After soldering, insert the CR2032 battery positive side up into the holder until the retaining clip snaps into place. To remove, use a plastic pry tool to release the clip. Precautions: do not exceed 200mA continuous current, avoid reverse polarity, ensure proper PCB land pattern, operate within -40 to +125 degrees Celsius. Advantages over competitors: Antenks holder features reinforced side walls and anti vibration latch, tested to withstand 10G vibration and 5000 insertion cycles. Coplanarity is controlled within 0.08mm to eliminate tombstoning during reflow. Low MOQs of 1000 units with no tooling fees for standard configurations.

Production process: in house mold design, injection molding on 10 Japanese and Taiwanese machines, high speed stamping on 9 presses, selective gold plating, automated assembly, 100 percent coplanarity and spring force inspection, contact resistance test, 48 hour salt spray test, and final QC with lot traceability. Free samples, 2D and 3D CAD drawings, and 24 hour technical support available. Contact Antenk for reliable CR2032 SMT coin cell holders.
