2.54mm Pin Header Single Row Angle Type standard shape

2 month ago

5 0 

5 year

Product details

Huizhou Antenk Electronics Co., Ltd. (IATF16949, ISO9001, ISO14001 certified) presents the 2.54mm Pin Header Single Row Angle Type in standard shape. This right angle pin header features a 2.54mm pitch, single row configuration, and a 90 degree bent orientation, allowing parallel PCB mounting and perpendicular cable connection. The insulator is molded from high temperature UL94 V-0 PBT or nylon 6/6, providing dimensional stability through wave or reflow soldering. Contacts are stamped from phosphor bronze with selective gold or tin plating on the mating area, and pure tin on the solder tails. Key specifications include current rating 3A per contact, contact resistance below 20 milliohms, insulation resistance above 1000 megohms, dielectric strength 500V AC, and operating temperature from -40 to +105 degrees Celsius. The standard shape offers a low profile with typical height of 5.0mm to 6.0mm after mounting. RoHS and REACH compliant, UL recognized under E472792.

Applications include PCB interconnections in consumer electronics, industrial controls, medical devices, communication equipment, and automotive modules. Usage method: solder the right angle through hole pins to the PCB using wave or hand soldering. Mate with a corresponding 2.54mm female header or IDC socket. The angled design saves board space and facilitates wire routing. Precautions: do not exceed 3A per contact, verify orientation before soldering, avoid excessive mating force. Advantages over competitors: Antenk maintains pin coplanarity within 0.05mm, ensuring uniform solder joint quality. The high temperature plastic withstands 260°C peak reflow, and selective gold plating guarantees stable contact resistance over 1000 mating cycles. Low MOQs of 1000 units with no tooling fees.

Production process: in house mold design, injection molding on 10 Japanese and Taiwanese machines, high speed stamping on 9 presses, selective gold or tin plating, automated pin insertion and right angle forming, 100 percent coplanarity and contact alignment inspection, contact resistance and insulation tests, 48 hour salt spray test, and final QC with lot traceability. Free samples, 2D and 3D CAD drawings, and 24 hour technical support available. Contact Antenk for custom pin lengths and plating.
