Machined Pin Connectors2.00 mm: MPHDS SQO.50MM Series

Our 2.00 mm MPHDS Series Machined Pin Connectors are precision engineered PCB solder tail connectors available in two structural types for flexible electrical connection needs. Type 1 is single row straight pin connector supporting 2 to 40 contact positions, while Type 2 is double row version with 1 to 80 contact options. The insulator adopts PPS material with UL 94V-0 flame retardant grade, fitted with brass sleeves and 3-finger beryllium copper contact clips compatible with 0.38 to 0.50 mm mating pins. In terms of electrical and mechanical features, this series carries a rated current of 1A, maximum contact resistance of 10 milliohms and minimum dielectric strength of 500V RMS, with a minimum service life of 500 mating cycles under standard insertion and withdrawal force. Users can install the connectors by soldering the straight tails onto printed circuit boards following standard PCB layout specifications. For safe application, operators should avoid forced plugging and unplugging beyond rated force, prevent overload current operation, control soldering temperature to protect insulating components, and dispose of waste products in line with RoHS and REACH environmental regulations to avoid environmental pollution.



All connectors are fully produced under our complete in-house industrial workflow covering precision mould development, terminal high-speed stamping, plastic injection molding, automatic connector assembly and laboratory reliability testing. Founded in 2007, Antenk operates a 10,000-square-meter production base in Dongguan with more than 250 professional employees, advanced imported precision punching machines, injection molding equipment, 250 sets of plastic moulds and 180 sets of hardware terminal moulds to achieve independent mass production. Compared with most peer manufacturers relying on outsourced processing, our brand holds the title of Guangdong Famous Trademark, certified by IATF16949 automotive quality management system, ISO9001, ISO14001 and UL safety standard. We provide multiple surface plating choices including tin and gold plating as well as diverse packaging modes of tray, bag, tube and tape reel. We own self-operated import and export rights with over 70 percent of products exported globally, and can issue 13 percent VAT invoices for global buyers. Our professional engineering and quality assurance teams implement full-process strict testing to eliminate unstable quality risks caused by outsourcing cooperation.



Benefiting from stable conductive performance and long service life, our machined pin connectors are widely applied in liquid crystal displays, digital cameras, industrial control devices, mobile storage products, digital home appliances, electronic toys, computer and network communication equipment, air conditioners, washing machines, automotive electronic systems and precision instruments. Our business covers major electronic industrial cities across China and stretches to dozens of countries and regions in Europe, Southeast Asia, the Middle East and South America. Supported by more than 10,000 mature connector specifications and independent research and development capabilities, we can deliver customized connection solutions for global purchasers rapidly. Every finished product undergoes strict laboratory inspection to meet international environmental and safety standards, helping global customers achieve stable, cost-effective and compliant electronic connection applications in diverse industrial and consumer electronic scenarios.
