Gold Plated Right Angle SCSI Connector 1.27mm Pitch PCB Header

This 1.27mm right angle SCSI female receptacle connector developed and manufactured by Antenk serves as a high speed stable signal transmission component for PCB ribbon connection, widely used to realize reliable electrical interconnection between circuit boards and peripheral devices. The product supports multiple pin specifications ranging from 14P to 50P with a standard 1.27mm pitch design, rated for 1A current, 500V AC one minute dielectric voltage resistance, maximum contact resistance of 25 milliohm and minimum insulation resistance of 500 megaohm, capable of stable operation under extreme temperature from minus 55 degrees Celsius to 125 degrees Celsius. Users can fix the connector onto the PCB through threaded inserts of different specifications, complete soldering for terminal pins and lock the nickel plated board locks to achieve firm assembly. It is applicable to industrial control equipment, communication devices, liquid crystal display modules, digital storage devices, precision testing instruments and computer peripheral hardware. Users must strictly follow the PCB dimensional tolerance of plus or minus 0.05mm during layout design, avoid excessive soldering temperature to prevent insulator deformation, and select matching male plug connectors to prevent terminal abrasion and poor contact. This connector complies with RoHS and REACH environmental standards and offers diversified gold plating options to meet long service life demands.



All Antenk 1.27mm pitch SCSI connectors are manufactured via full in house standardized production processes including independent precision mold development, high speed hardware terminal stamping, glass fiber reinforced plastic injection molding, electroplating surface treatment, automatic assembly and strict electrical performance reliability testing. Founded in 2007, our company runs a 10000 square meter manufacturing base in Dongguan with dedicated workshops for mold fabrication, terminal stamping and plastic molding, equipped with over 18 precision mold processing machines, 11 high speed punching equipment and 8 plastic injection molding machines. Unlike outsourcing dependent manufacturers, we own 250 sets of plastic connector molds and 180 sets of precision terminal molds to realize full chain self production. Our factory has passed UL safety certification, ISO9001, ISO14001 and IATF16949 quality management certifications, holds general taxpayer qualification and independent import and export rights with over 70 percent of products exported worldwide. We provide flexible pin count customization, multiple plating choices and formal VAT invoices, delivering more stable quality, shorter lead time and comprehensive technical support compared with peer competitors.



As a Guangdong Famous Trademark brand, Antenk arranges professional quality assurance teams to conduct strict sampling inspections on dimensional accuracy, conductive stability and high low temperature resistance for every batch of SCSI connectors. Adopting high temperature resistant PBT material, copper alloy terminals and zinc alloy shielding shell with standardized nickel and gold plating treatment, this product effectively resists oxidation, electromagnetic interference and mechanical wear for long term continuous operation. Our connector products have gained high recognition from purchasers across North America, Europe, Southeast Asia and other global regions, and we can supply more than 10000 kinds of precision connector specifications to provide one stop electronic connection solutions. To extend product service life, operators shall avoid over current overload and violent plugging and unplugging in actual use. We offer detailed engineering drawings, customized packaging solutions and long term after sales technical service, helping global buyers streamline supply chain management and reduce procurement and quality risks.
