2.00mm SMT Single Row Pin Header With Post for Fresto-SPAN-B

This 2.00mm single row SMT pin header produced by Antenk Electronics is a reliable board to board connecting component dedicated to stable power supply and signal transmission between printed circuit boards. Designed with a standard 2.00mm pitch and 0.51 square millimeter pins, this connector supports contact pin counts ranging from 1 pin to 40 pins to meet diverse circuit layout demands. It features a rated current of 1.5 Amp, minimum insulation resistance of 1000 megaohms, maximum contact resistance of 20 milliohms and 500V AC dielectric withstand voltage, performing steadily within a wide operating temperature range from minus 65 degrees Celsius to 125 degrees Celsius. The insulator adopts black PA6T material with UL94V0 flame retardant rating, and the conductive pins are made of brass with multiple selective gold plating and tin plating options for superior anti oxidation and conductive performance. During assembly, users attach the pin header to designated PCB pads via SMT reflow soldering technology, and the positioning structure ensures precise placement before mating with matching female connectors to complete circuit connection. All products comply with RoHS and REACH environmental standards. In application, users should avoid excessive plugging force to prevent pin deformation, and keep working temperature within the specified range to prevent plastic aging and electrical short circuit faults.



Antenk Electronics holds prominent competitive advantages compared with other connector manufacturers in the global market. Founded in 2007, our company operates production bases in Shenzhen and Dongguan covering over 10000 square meters with more than 250 professional employees. Equipped with Taiwan high speed precision stamping machines, imported plastic injection molding equipment and full set of professional testing instruments, we independently complete the whole production process including mold design and development, brass terminal stamping, plastic injection molding, electroplating surface treatment, automatic assembly and rigorous laboratory performance inspection. We own over 250 sets of plastic connector molds and 180 sets of precision hardware terminal molds, supporting customized adjustment on pin length, plating thickness, insulating material and packaging mode for global clients. Our factory has obtained ISO9001, ISO14001 and IATF16949 quality management system certifications, and most products pass UL safety certification with certificate number E472792. As a general taxpayer with self operated import and export rights, we can issue 13 percent VAT invoices, and our proprietary ANTENK brand has been awarded Guangdong Famous Trademark. More than 70 percent of our products are exported worldwide, delivering stable quality, on time delivery and comprehensive technical support that most small scale factories cannot match.



This single row SMT pin header has extensive application coverage across multiple electronic industries. It is widely used in liquid crystal display devices, digital cameras, communication equipment, industrial control systems, mobile storage devices, smart home appliances, electronic toys, computer peripheral products, automotive electronic modules, precision testing instruments and various intelligent control equipment. Every batch of finished connectors undergoes strict reliability tests including high low temperature cycle test, tensile strength test, insulation performance detection and flame retardant verification before delivery. Multiple packaging options such as tray, bag, tube and tape reel are available to adapt to automatic mass production requirements. We provide personalized structural and surface treatment customization services for global purchasers, and our stable and cost effective connecting solutions have gained consistent trust from buyers in North America, Europe, Southeast Asia, South America and other global regions.
