MS25 Multi-Purpose Hydraulic Motor - Detailed Information
I. Product Overview
The MS25 Multi-Purpose Hydraulic Motor is a high-performance hydraulic motor produced by POCLAIN HYDRAULICS. It features a modular design, a wide displacement range, high output torque, and the ability to withstand high-pressure working conditions. It is widely used in various fields such as construction equipment, material handling, agriculture, environmental applications, mining, railways, marine vessels, and industrial applications, making it an ideal choice for wheel-end drives or tool drives.
II. Product Features
1. Modular Design: The MS25 hydraulic motor adopts a modular design concept, making it easy to use in all demanding applications in the most demanding markets. Users can flexibly configure and combine different modules according to actual needs to meet various working requirements.
2. Wide Displacement Range: The displacement range of the MS25 hydraulic motor is from 2004 to 3006 cc/rev. Users can select the appropriate displacement based on actual needs to achieve optimal performance and efficiency.
3. High Output Torque: Under a pressure of 100 bar, the maximum torque of the MS25 hydraulic motor can reach 21,500 N.m, meeting the demands of heavy-duty starting and stable low-speed operation.
4. High-Pressure Adaptability: The MS25 hydraulic motor can withstand a maximum pressure of up to 450 bar, making it suitable for high-pressure working conditions.
5. Multi-Speed Concept: The MS25 hydraulic motor is designed with a multi-speed concept, with a maximum rotational speed of up to 145 rpm, meeting the needs of different rotational speeds.
6. Easy Maintenance and Upkeep: The structural design of the MS25 hydraulic motor is reasonable, making it easy to disassemble and install, facilitating user maintenance and upkeep.
III. Technical Parameters
Here are some common technical parameters for the MS25 Multi-Purpose Hydraulic Motor:
【表格】
Parameter Value
Displacement Range 2004 to 3006 cc/rev
Maximum Torque 21,500 N.m (under 100 bar pressure)
Maximum Pressure 450 bar
Maximum Power 90 kW
Maximum Rotational Speed 145 rpm
IV. Application Scenarios
Due to its outstanding performance and wide adaptability, the MS25 Multi-Purpose Hydraulic Motor is widely used in the following fields:
1. Construction Equipment: Such as excavators, loaders, and road rollers, for achieving movements like walking, rotation, and excavation.
2. Material Handling: Such as forklifts and cranes, for lifting and handling goods.
3. Agricultural Machinery: Such as harvesters and tractors, for power output and control in agricultural operations.
4. Mining Machinery: Such as mining trucks and excavators, for providing reliable power support in harsh mining environments.
5. Railways and Marine Vessels: For power output and control systems in railway vehicles and marine vessels.
6. Industrial Applications: Such as rolling mills and continuous casting machines, for providing powerful power output and precise control performance.
