3.5mm Pitch Dual Row Straight Pin Header Dip Type

Manufactured by Huizhou Antenk Electronics Co., Ltd, the 3.5mm pitch dual row straight pin header of PHKS01 series is designed to realize stable power transmission and reliable signal connection between circuit boards. This DIP type connector adopts copper alloy as contact material, with optional gold plating or tin over nickel plating, and the insulator is made of LCP filled with 30 percent glass fiber that meets UL94V 0 flame retardant standard. It supports a maximum current of 14 Amp, features 100M ohm minimum insulation resistance at 500V DC and 20m ohm maximum contact resistance, and can withstand 500V AC voltage within one minute under wide operating temperature ranging from minus 40 degrees Celsius to 125 degrees Celsius. Our complete production workflow includes independent mold design and development, precision terminal stamping, high temperature resistant plastic injection molding, surface plating treatment, automatic assembly and strict electrical performance testing in professional laboratories. Equipped with imported high speed punching machines and precision injection molding equipment, this pin header covers circuit specifications from 4 circuits to 20 circuits with two optional pin lengths to match diverse PCB layout requirements, and all dimensional tolerances are precisely controlled according to industrial standards.



This dual row straight pin header applies traditional through hole DIP welding technology, compatible with automatic wave soldering and manual welding operations for PCB mounting. It is widely used in industrial control equipment, automotive electronic modules, communication facilities, smart home appliances, precision testing instruments, computer peripheral equipment and consumer electronics. During usage, operators should strictly follow the recommended PCB layout parameters for plug in welding, avoid excessive welding temperature and duration to prevent deformation of the LCP insulator, and keep pin terminals away from dust, moisture and corrosive chemical substances to guarantee long term stable electrical performance. All products comply with EU RoHS and REACH environmental directives, most items pass UL certification with the certificate number E472792, and our production system is certified by ISO9001, ISO14001 and IATF16949 automotive industry quality management system, with multiple packaging choices including bag tube and tape reel to satisfy different production demands.



Compared with other connector suppliers, Antenk owns more than 250 sets of plastic molds and 180 sets of precision metal terminal molds, enabling rapid customized adjustment on pin count, pin length, surface plating and packaging methods for this pin header series. Our 10000 square meter manufacturing base in Guangdong Province has 250 experienced staff, over 180 automatic assembly machines and 20 sets of professional testing devices, which ensures stable product consistency and large scale delivery capacity. As an enterprise holding Guangdong Famous Trademark qualification, more than 70 percent of our products are exported globally. Our full range of incoming in process and finished product inspection standards effectively reduce product defect rates, and the high temperature resistant and high current bearing performance of our pin headers outperforms ordinary peer products, helping us build long term cooperative partnerships with customers across North America, Europe, Southeast Asia and other global regions.
