Automatic Rapid Gate Industrial Dust-Proof Storage Hygienic Room Safety Fast Rolling Curtain High Speed Roll up Polyvinyl Chloride PVC Rolling Shutter Door1
2 week ago
Product details
PVC Fast Rolling Up Shutter Door for Clean Room & Warehouse – CE & ISO9001 Certified
PVC Fast Door Packaging & Delivery
Package Size
300.00cm * 35.00cm * 35.00cm
Package Gross Weight
150.000kg
Product Description
PVC Fast Door, also called fast soft door,which is a barrier door with rapid rise and fall.And its main function is quickly isolation, thus to ensure the air quality of the workshop without dust. High speed shutter door has the functions of heat preservation, cold preservation, insect-proof, windproof, dust proof, sound insulation, fire proof, anti odour, day lighting and so on. It is widely used in food, chemistry, textile, electronics, supermarket, freezing, logistics, storage and other places. It can meet the need of high performance logistics and clean place, saving energy for shutting down automatically. What's more, it can improve working efficiency, create better working environment and so on.
Easy installation.
Installation manual and video available.
The door is pre-assembled in factory.
The installation holes on the guide rail, shaft are predrilled in factory.
Installation manual and video available.
The door is pre-assembled in factory.
The installation holes on the guide rail, shaft are predrilled in factory.
High Quality PVC Fast Door Parts
Door frame:
Made of aluminum alloy, stainless steel, or high-quality sprayed galvanized steel plate.
Bottom edge: Safety air bottom can be configured.
Door curtain:
- Made of high-quality high-strength PVC material industrial base fabric and T60 aluminum alloy wind resistant ribs.
- Curtain color is optional, with a transparent window in the middle and a height of 400mm.
- The thickness of the door curtain base fabric is 0.8mm or 1mm, and the PVC coated fabric has double-sided self-cleaning function (can be cleaned with water).
- The surface of the wind resistant rib aluminum profile is treated with oxidation.
- The service life of the door curtain is 8-10 years.
- The tear resistance strength is ≥ 800KN/m.
Features
Fast running speed:
Speed adjustable, opening speed of 0.6-2.0m/s, closing speed of 0.6-1.0m/s, providing fast isolation.
Motor: Flexible start and stop, optional geomagnetic, radar, infrared, light curtain, etc.
Fire resistance level: B1 level.
The curtain fabric is flame-retardant, self extinguishing upon ignition, and has a B1 level fire resistance.
Wind resistance performance:
Suitable for indoor door opening installation under wind pressure or negative pressure<35kg/m2. Maximum wind resistance capacity of level 10 (referring to instant resistance to level 10 strong winds)
Fast running speed:
Speed adjustable, opening speed of 0.6-2.0m/s, closing speed of 0.6-1.0m/s, providing fast isolation.
Motor: Flexible start and stop, optional geomagnetic, radar, infrared, light curtain, etc.
Fire resistance level: B1 level.
The curtain fabric is flame-retardant, self extinguishing upon ignition, and has a B1 level fire resistance.
Wind resistance performance:
Suitable for indoor door opening installation under wind pressure or negative pressure<35kg/m2. Maximum wind resistance capacity of level 10 (referring to instant resistance to level 10 strong winds)
| Product name | PVC Fast Door |
| Curtain Material | High speed PVC cloth and Aluminum wind bar |
| Sealing | EPDM rubber or industrial hairbrush |
| Guide rail and Frame materials | Steel, Aluminum, Stainless steel optional |
| Opening speed | 0.6-1.5 m/s(adjustable) |
| Opening direction | Rolling |
| Motor Voltage | 110v \220V \380v |
| Opening style | Remotes, sensor, Wifi, Radar, wall switch |
| Advantage | lower energy costs |
| Application | factories, workshops, warehouses |
Yuema is a professional manufacturer of steel and aluminum roller doors, sectional garage doors, industrial doors, and high-speed doors. Our factory is located in Shenzhen , With over 10 years of experience in the industry, we are a leading supplier and provide OEM services to many companies across the EU, US, and Oceania. Our advanced production lines are backed by lS09001 certifcation and we adhere to strict quality control procedures to ensure that our products meet the highest standards. We welcome your inquiries or visits and look forward to building a long-term, win-win partnership with you.
