3.96mm 180 Degree Vertical Wafer Connector



1、Product Description

Manufactured by Huizhou Antenk Electronics Co., Ltd, the AW3962V series 3.96mm pitch 180° Wafer Connector is vertical through-hole wire-to-board socket dedicated to stable signal and low-power electrical connection between wires and printed circuit boards. All manufacturing operations are strictly carried out in accordance with dimensional markings and tolerance standards on official engineering drawings. The insulating housing is crafted from Nylon 66 material meeting UL94V-2 flame retardant grade, delivering reliable insulation and outstanding temperature resistance. Conductive pins are brass finished with full tin plating to reduce contact resistance and resist surface oxidation effectively. This connector is rated 250V alternating and direct voltage with 7A rated current, featuring insulation resistance above 1000 megohms and 1500V one-minute dielectric withstand voltage, operating reliably within the temperature range of minus 25 degrees Celsius to 85 degrees Celsius. The series offers flexible pole options ranging from 2 pins to 20 pins with standardized unified dimensions for each specification. Our complete production workflow covers independent precision mold development, high-speed brass terminal stamping, tin electroplating treatment, nylon plastic injection molding, automatic pin pressing assembly and finished dimensional & electrical inspection. Advanced Japanese and Taiwanese production equipment guarantees consistent 3.96mm pitch precision, and all raw materials fully comply with EU RoHS and REACH environmental directives.



This 180-degree vertical wafer connector features simple and convenient assembly steps. Operators solder the vertical straight pins firmly onto PCB through holes firstly, then insert the matched crimped wire housing into the wafer socket to form detachable wire-to-board connection loops. The universal 3.96mm pitch enjoys high compatibility with mainstream wire harnesses widely used in electronic industry. It is extensively applied in industrial control panels, household digital appliances, display screens, power adapters, portable consumer electronics and precision testing instruments. During application, users must never exceed the rated 7A current to avoid pin overheating and insulator melting damage. Frequent violent plugging and unplugging should be avoided to prevent pin loosening and housing fracture. Unused connectors must be stored in dry sealed surroundings to protect tin plating layers from oxidation. Most product specifications obtain UL certification numbered E472792, and our factory holds ISO9001, ISO14001 and IATF16949 complete quality management certifications.



Compared with other electronic connector manufacturers, Antenk independently develops and owns more than 250 sets of plastic injection molds and 180 sets of precision metal stamping molds, supporting customized pole counts, plating thickness and optional insulation colors for this wafer connector series. Our 10000 square meter manufacturing workshop hires 250 professional skilled staff, equipped with over 180 automatic assembly machines and 20 sets of professional electrical testing equipment, ensuring stable mass production output and punctual shipment for large overseas export orders. As a brand awarded Guangdong Famous Trademark certification, more than 70 percent of our electronic connectors are exported to Europe, America, Southeast Asia and South America across the globe. We accept small batch trial orders for standard items without extra expensive mold opening fees.



We implement strict full-process quality inspection for every batch of 3.96mm wafer connectors, including incoming raw material inspection, real-time process monitoring for stamping, electroplating and injection molding procedures, finished contact resistance testing, high voltage withstand testing and plug service life cycle testing. Each production batch retains complete lot traceability records for full quality tracking. Multi-layer rigorous inspection greatly enhances long-term connection stability and anti-vibration performance, effectively eliminating hidden circuit troubles triggered by poor contact. We provide free product samples, detailed PCB layout drawings and 24-hour online technical support for all global purchasers, establishing long-term trusted cooperative partnerships with electronic manufacturers worldwide.
