Product details

Material Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy

Shape   Bar,Pipe/tube,sheet/plate,Forging,Ring,Coil,Flange,Ribbon,Square pipe/bar,product processing

Grade Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L

Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc

Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC

Incoloy: Incoloy 800/800H/800HT/825/925/926;etc

GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc

Monel: Monel 400/K500/R405,etc

Nitronic: Nitronic 40/50/60;etc

Nimonic: Nimonic 75/80A/90/A263 ;etc

Specification Wire: 0.01-10mm

Strip: 0.05*5.0-5.0*250mm

Bar: φ4-50mm;Length 2000-5000mm

Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm

Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm

Product Characteristics

1.According to the preparation process can be divided into deformation superalloys,

casting superalloys and powder metallurgy superalloys.

2.According to the strengthening mode, there are solid solution strengthening type, precipitation

strengthening type, oxide dispersion strengthening type and fiber strengthening type, etc..

Inspection ISO,SGS,BV and so on.

Packaging All our products are packed, stored, transported according to the international regulation.Or as customer's requirement provide special packing.



Inconel 718

Features:   Inconel 718 is a nickel-chromium-molybdenum alloy designed to resist a wide range of severely corrosive environments, pitting and crevice corrosion. This nickel steel alloy also displays exceptionally high yield, tensile, and creep-rupture properties at high temperatures. This nickel alloy is used from cryogenic temperatures up to long term service at 1200° F. One of the distinguishing features of Inconel 718’s composition is the addition of niobium to permit age hardening which allows annealing and welding without spontaneous hardening during heating and cooling. The addition of niobium acts with the molybdenum to stiffen the alloy’s matrix and provide high strength without a strengthening heat treatment. Other popular nickel-chromium alloys are age hardened through the addition of aluminum and titanium. This nickel steel alloy is readily fabricated and may be welded in either the annealed or precipitation (age) hardened condition. This superalloy is used in a variety of industries such as aerospace, chemical processing, marine engineering, pollution-control equipment, and nuclear reactors.

Chemical Composition

Ni Cr Fe C Mn Si Mo Cu
50-55 17-21 balance 0.08 max 0.35 max 0.35 max 2.8-3.3 0.3 max
Co Al Ti Nb B P S
1.0 max 0.20-0.80 0.65-1.15 4.75-5.50 0-0.006 0.01 max 0.01 max

Density and Melting point

Density Melting point
8.24g/cm³ 1260-1320

 Mechanical Properties

Finish Condition Tensile strength Rm N/mm² Yield strength R P 0. 2N/mm² Elongation (A 5%) Min  HB
Solution treatment 965 550 30 ≤363
