SOLENOID VALVE DSD-G03-6C-DC24-82
Product Overview
DSD-G03-6C-DC24-82 is a 7OCEAN seven-ocean solenoid directional Hydraulic valve, which acts as a core direction control component for the hydraulic system of industrial Machine. This Hydraulic valve adopts NG10 standard mounting surface, three-position four-way structure with DC24V solenoid coil. It changes the flow path of hydraulic oil inside the hydraulic system to control the extension and retraction of hydraulic cylinders and other actuators.
The DSD-G03 series Hydraulic valve features optimized spool design, large rated flow and low flow force impact. It delivers stable reversing performance and low internal leakage. Widely fitted on hydraulic power stations, machine tools and automation Machine, it can accurately switch oil directions to realize various movement actions of equipment.
Technical Specifications
- Model: DSD-G03-6C-DC24-82
- Type: Solenoid directional Hydraulic valve
- Mounting standard: ISO4401 NG10
- Coil voltage: DC24V
- Spool function: 6C spool, 3-position 4-way, spring centered
- Max working pressure: 31.5MPa
- Rated flow: 80L/min
- Working medium: Anti-wear hydraulic mineral oil
- Protection grade: IP65
- Application: Direction control of hydraulic system for industrial Machine
- Feature: Large flow capacity, smooth shifting, durable long-cycle operation
Working Principle
When the Machine supplies DC24V power to the coil of this Hydraulic valve, electromagnetic force pushes the internal valve spool to shift and reconfigures the oil passages of the hydraulic system. High-pressure hydraulic oil is guided to hydraulic actuators to drive the Machine to perform preset movements. When the coil is de-energized, the centering spring automatically returns the spool to the middle position, cutting off the main oil circuit and stopping the actuator movement. This Hydraulic valve precisely manages oil flow direction and keeps the whole hydraulic system running safely and orderly.
Core Advantages
1. Standard NG10 ISO4401 installation dimension, convenient assembly and interchangeability for the hydraulic system of Machine.
2. Precision ground valve spool structure, low internal leakage and smooth reversing without sticking, stable for heavy continuous operation.
3. DC24V coil with IP65 protection rating, good dustproof and moisture resistance, adaptable to factory workshop environments.
4. Optimized flow channel design, high flow capacity, reduces pressure loss and heat generation of the hydraulic system.
5. Suitable for hydraulic power pack, injection molding machine, metallurgical machinery and automation equipment overhaul & spare part stocking.
Application Range
DSD-G03-6C-DC24-82 Hydraulic valve serves as directional control element in hydraulic system of hydraulic power units, plastic injection machines, machine tools, metallurgical equipment and other industrial Machine. It controls hydraulic cylinder reciprocating motion for new machine assembly and maintenance replacement.
