Product details

Hydraulic Nut Breaking Tool

The hydraulic nut breaking tool is a type of split hydraulics disassembly tool used to work with rusted, seized and over tightened hex nuts in oil and gas, equipment repair and chemicals processing industry among other applications and this hydraulic nut breaker breaks rusted or frozen nuts without killing the bolt thread underneath. Constructed of high upgraded steel and heat treated cutting blade, this MARSHINE Split Hydraulic Crimping Tool comes with quick-couple fitting to attach external manual or electric hydraulic pump for easy jobsite use. This manual hydraulic nut breaker is designed for confined areas, such as pipe flanges and equipment frames, and that delivers a focused splitting force without subjecting adjacent components to shock damage. This hydraulic nut removal tool is made to save you from grinding and torch cutting onsite labor and it can remove more stubborn rusted fasteners than normal spanners could ever loosen.

Therefore the bolt is compressed and the full bolt tensile load is transferred to the bolt itself, which is compressed and shortened if it is not strong enough.

This MARSHINE Manual Hydraulic Nut Breaker can be achieved 2,000 times per minute working speed, 20 mm length of stroke and 14 ton maximum output force for suitable bolt size M8-M27 bolt thread, and for nut flat 14-41 mm.

The breaking head is a separate unit, 4.5kg it runs on standard 70megapascal hydraulic oil input pressure.

This hydraulic nut removal tool has a hardened and replaceable blade that will not chip when splitting high-strength grade 8.8 rusted nuts.

The split-head design permits the operator to slip the tool over nuts while they are turning without first having to remove any other parts in the vicinity.

The entire kit comes in a metal case to protect the tool assembly when being transported around the workshop or between field and workshop.

The hydraulic nut break tool provides hour striker nut removal in industrial equipment shutdown maintenance works.

Hydraulic nut breaker tool enables fast, safe disassembly of rusted fasteners for flange service inside chemical processing plants.

Hydraulic nut breaker portable hydraulic nut breaker emergency repair on site for heavy equipment left outdoors for a long time rust.

This MARSHINE Hand Hydraulic Nut Breaker greatly speeds up service work in confined spaces on equipment where large hand wrenches just won't fit.

The hydraulic nut removel tool is now available to take the pain out of seized bolts and nuts for MS and industrial maintenance teams spread over many sites.

By minimizing damage to surrounding components, the hydraulic nut removal cutter protects and improves the efficiency of mechanical repair teams around the globe.

Parameter

Model	Tonnage	Stroke	Bolt Range	Hex Nut AF Range	Weight
JK-24F	10 T	20 mm	M8-M24	M8-M24	3.15 kg
JK-27F	14 T	20 mm	M8-M20/M22-M27	13-30/32-41 mm	3.8/5 kg
JK-30F	20 T	20 mm	M10-M22/M24-M30	16-32/36-46 mm	4.6/6.5 kg
