Field Portable Non-Methane Hydrocarbon Detector

Core Functions & Basic Features

This integrated solution is built around Portable VOC Analyzer and Hydrogen Generator technologies, delivering all-in-one detection and gas supply.

It supports real-time qualitative and quantitative analysis of Volatile Organic Compounds (VOC), Non-methane Hydrocarbons (NMHC), and multiple toxic and hazardous gases.

Adopts high-sensitivity Portable Flame Ionization Detector (FID) for fast response and stable readings.

Built-in hydrogen supply module eliminates the need for external cylinders, improving mobility and safety.

Portable, lightweight, rugged housing for field, high-temperature, and high-humidity environments.

One-key operation, automatic calibration, data storage, and digital output for easy reporting.

Multi-gas simultaneous detection with clear real-time display of concentration, trend, and alarm status.

Performance Parameters

Detection principle: Flame Ionization Detection (FID)

Supported targets: VOCs, NMHC, total hydrocarbons, and typical toxic & hazardous gases

Detection range: 0–10000 ppm (customizable upon request)

Resolution: 0.1 ppm

Response time: ≤ 15 seconds

Flow rate: 500 mL/min – 1000 mL/min

Hydrogen purity: Up to 99.999%

Working temperature: -10°C to 50°C

Power supply: rechargeable lithium battery, 6–8 hours continuous operation

Protection level: IP65 dust‑proof and splash‑proof

Communication: USB, Bluetooth, optional wireless transmission

Size & weight: compact handheld/backpack design, ≤ 5.5kg

Core Advantages

Integrated detection & hydrogen supplyThe built-in Hydrogen Generator provides stable, high-purity hydrogen for the FID detector, removing reliance on external cylinders. This greatly improves mobility, safety, and continuity for long-duration field jobs.

Superior sensitivity & stabilityEquipped with premium FID sensing components and optimized gas path design, it delivers low interference, high repeatability, and long service life. It maintains stable performance in complex field conditions.

Truly portable & user-friendlyLightweight, ergonomic, and durable, it supports one-hand operation and long-time use. The intuitive interface reduces training cost and improves on-site efficiency.

Safety-focused designMultiple built-in protections: overpressure, overtemperature, water shortage, leakage alarm, and automatic shutdown. It ensures safe operation in high-risk industrial environments.

This integrated Portable Gas Analyzer system combines Portable VOC Analyzer, NMHC Analyzer, FID detection, and Hydrogen Generator into one professional solution. It delivers high precision, strong stability, and excellent portability for on‑site gas analysis. It is a reliable tool for environmental compliance, industrial safety, and emergency response, helping users improve detection efficiency, reduce operational risks, and meet regulatory requirements with confidence.
