C113684 Diaphragm
3 year ago
Product Description:
This is C113684 diaphragm repair kit for ASCO 2'', 2-1/2'' G353A048, G353A049 pulse jet valve. The diaphragm is the most important part of the pulse valve. When the pulse valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pulse valve is de-energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the pulse valve.
Technical Data of Pulse Valve Diaphragm:
|
Suitable Pulse Valve Model |
Diaphragm Model |
Diaphragm Material |
|
G353A041, G353A042 |
C113443 |
TPE / NBR |
|
SCG353A043, SCG353A044 |
C113444 |
TPE / NBR |
|
G353A045 |
C113825 |
NBR |
|
G353A046 |
C113826 |
NBR |
|
SCG353A047, SCG353A065 |
C113827 |
NBR |
|
G353A048, G353A049 |
C113684 |
NBR |
|
SCG353A050, SCG353A051 |
C113685, C113686 |
NBR |
|
SCXE353.060 |
C113928 |
NBR |
|
8353H038 |
276886 |
HYT |
|
8353J039 |
322108 |
HYT |
Main Dimension:
More Details:
 |
 |
 |
 |
| Pulse Valve Coil | Pulse Valve Armature | Pulse Jet Valve | Pulse Controller |
Packing & Shipping:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
