Cable Anti Twist Running Board

The MARSHINE is focused on producing safe and reliable tools to meet the needs of power grid projects, whcih can provide a full line of cable and fiber optic installation products. The MARSHINE Cable Anti Twist Running Board is a tension seperation cable running plate that can be used to prevent cable twisting and running conductor smoothly. This tool is suitable for 220kV scale-500kV high voltage transmission line construction, which can support three conductor with a rated load of 180kN in tension erection.

The MARSHINE Cable Anti Twist Running Board is designed for large diameter power cables, and its rated load of 180KN that suitable for heavy traction operation.

It can be used with 110 mm wide pulleys, which makes it suitable for the most commonly used tension erection equipments.

This conductor running board has a weight of 142 kg, which can make the traction plate achieves perfect balance between load-bearing and ease of operation at site.

The integrated anti torsion with balancing pulley and anti torsion cable, which can make it stop conductor crossing or twisting during traction.

The stringing running board is widely used in overhead transmission line for the prevention of conductor twisting when the conductor through the pulleys with the width of 110mm.

It can be used for the renovation of city power channel, and can be used at the limited space to traction big cables smoothly.

This MARSHINE Pulling Running Board can be applied to crossing-river transmission line project, the bearing load is large, and it can traction long spans of conductors.

It also promotes the new energy transmission line project.

Product Parameter

Product Serial Number	Model	Rated Load (kN)	Applicable Pulley Groove Width (mm)	Weight (kg)	Steel Wire Rope Length (m)
17228	SZ3A-10	100	100	114	1×30+1×15
17229	SZ3A-13	130	110	130	1×30+1×15
17230	SZ3A-18	180	110	142	1×30+1×15
