Steel Ground Screw are widely used in the ground support system of solar panels.It is easy to screw into the ground,and the galvanizing treatment on the surface of the Ground Screws can ensure that the use of the Ground Pile is longer and more stable.The color of the Ground Pile after hot dip galvanizing is usually silver,and the surface of Screw Piles can also be epoxy sprayed.The surface color of the Ground Screw Piles after treatment can be green or other colors,so that the surface of the spiral piles will be smoother and more beautiful,and the appearance of the product will be more beautiful.

Material: Carbon steel S 235 or S 350

Production processing: designed Ground Screw and make drawings for Ground Screw ,cutting steel pipe ,shrank tip of tube according to Ground Screw design ,welding blade and flange ,acid pickling ,hot dip galvanized treatment ,polish zinc drips .packing .

Frequently used size of flange:200*8 mm,220*8 mm .

Shape of flange:round,hexagon,triangle,square ,rectangle & ,according to clients' need.

Some size of Ground Screw Anchor:

76*3*1200 mm

76*3*1500 mm

76*3*1800 mm

76*3*2000 mm

89*3.75*1500 mm

89*3.75*2000 mm

102*4*1800 mm

102*4*2000 mm .

Diameter of pipe:76 mm,89 mm,102 mm,114 mm.
