P4.81 Outdoor Rental Event LED Screen
4 year ago
Product Introduction
P4.81 Waterproof Outdoor Rental LED Screen Wall 500*1000 is a reliable and high-quality LED display that is perfect for outdoor events and rental applications. Its durability, high refresh rate, and wide viewing angle make it a popular choice for many event organizers and rental companies.
The LED screen wall is made of high-quality materials that are durable and long-lasting. It has a high refresh rate and brightness, ensuring that the images displayed are of high quality and can be seen clearly even in bright sunlight. The LED screen wall is also energy-efficient, reducing power consumption and saving on energy costs.
The Stage Pantalla Led Screen P4.81 Waterproof Outdoor Rental LED Screen Wall 500*1000 has a wide viewing angle, allowing people to view the display from different angles without any distortion. It is also lightweight and easy to transport, making it ideal for use in outdoor events such as concerts, sports events, and festivals.
Application
The P4.81 Waterproof Outdoor Rental LED Screen Wall 500*1000 is a high-quality LED display designed for outdoor events and rental applications. It features a pixel pitch of 4.81mm, which provides clear and sharp images even from a distance. The LED screen wall is waterproof, making it suitable for use in all weather conditions. The 500*1000mm panel size is easy to install and dismantle, making it ideal for rental applications.
Packing Solution
Packing way: Flight case
Data Sheet
| MAIN TECHNICAL PARAMETERS FOR INDOOR LED DISPLAY(PITCH4.81) | |||
|
（Technical parameters） |
UNIT |
（ parameters values ） |
|
|
（Pixel pitch） |
MM |
4.81 |
|
|
（Panel size） |
MM |
L250*H250*T13 |
|
|
（Physical density） |
/M2 |
43264 |
|
|
（Pixel configuration） |
R/G/B |
1,1,1 |
|
|
（Driving method） |
|
1/13 Constant current 1/13scan |
|
|
（LED Encapsulation） |
SMD |
1921 white |
|
|
（Display resolution） |
DOTS |
52*52=2704 |
|
|
（Module weight） |
KG |
0.25 |
|
|
（Module port） |
|
HUB-HD75B(1) |
|
|
（Module working voltage） |
VDC |
5 |
|
|
（Module consumption ） |
W |
28 |
|
|
Panel Parameters |
|||
|
（Viewing angle） |
Deg. |
140 |
|
|
（Option distance） |
M |
4-30 |
|
|
（Driving device） |
|
IC:2038S/2153 |
|
|
（Every square metre module） |
PCS |
16 |
|
|
（Maximum power） |
W/ M2 |
450 |
|
|
（Frame Frequency） |
HZ/S |
≥60 |
|
|
（Refresh frequency） |
HZ/S |
≥1920/3840HZ |
|
|
（Equilibrium brightness） |
CD/ M2 |
≥5500-6500mcd |
|
|
（Working environment temperature） |
0C |
-10~60 |
|
|
（Working environment humidity） |
RH |
10%～70% |
|
|
（Display working voltage） |
VAC |
AC47~63HZ，220V±15%/110V±15% |
|
|
（Colour temperature） |
|
7000K-10000K |
|
|
（Gray scale/color） |
|
≥16.7M color |
|
|
（Input signal） |
|
RF\ S-Video\ RGB etc |
|
|
（Control system） |
|
NovaStar Linsn Coloright |
|
|
（Mean free error time） |
HOURS |
＞5000 |
|
|
（Life） |
HOURS |
100000 |
|
|
（Lamp failure frequency） |
|
＜0.0001 |
|
|
（Antijam） |
|
IEC801 |
|
|
（Safety） |
|
GB4793 |
|
|
（Resist the electricity） |
|
1500V last 1min No breakdown |
|
|
（IP rating） |
|
The back IP40，The front IP56 |
|
|
（Steel box size） |
mm |
L500*h1000/500x1000 |
|
