Product Description

Galvanized steel pipe is a steel pipe that has been coated with a layer of zinc. This coating protects the steel from corrosion. It is most commonly used in outdoor construction like fences, handrails, and scaffolding. Galvanized steel pipe is also used in plumbing applications, particularly for water supply lines. The zinc coating on the pipe prevents corrosion and extends the life of the plumbing system. Galvanized steel pipe comes in a variety of sizes and thicknesses to suit different applications.

The main specification of the galvanized steel pipes as below:

DN	Size	Outside diameter  mm	Wall thickness mm	Minimum wall thickness mm	Weight per Meter kg	Weight per Pcs kg	Weight per Meter Kg	Weight per Pcs kg
DN15	1.2	21.3	2.8	2.45	1.28	7.68	1.357	8.14
DN20	3.4	26.9	2.8	2.45	1.66	9.96	1.76	10.56
DN25	1	33.7	3.2	2.8	2.41	14.46	2.554	15.32
DN32	1.25	42.4	3.5	3.06	3.36	20.16	3.56	21.36
DN40	1.5	48.3	3.5	3.06	3.87	23.22	4.1	24.6
DN50	2	60.3	3.8	3.325	5.29	31.74	5.607	33.64
DN65	2.5	76.1	4	3.5	7.11	42.66	7.536	45.21
DN80	3	88.9	4		8.38	50.28	8.88	53.28
DN100	4	114.3	4		10.88	65.28	11.53	69.18

Product detail

Length	3-12M according to client requirement
Standard	EN10255, EN10219, EN10210, EN39, BS1387, ASTM A53, ASTM A500, ASTM A36, API 5L, ISO 65, JIS G3444, JIS3452, DIN 3444, ANSI C80.1, AS 1074, GB/T 3091
Material	Gr.A, Gr.B, Gr.C, S235, S275, S355, A36, SS400, Q195, Q235, Q345
Certificate	ISO 9001:2008,SGS, BV, CCIC etc
Finish of pipe	Hot dipped galvanized with zinc 200~260g/m2;
	Pre-Galvanized with zinc 30~150g/m2
	Painted with black/varnish lacquer;
	Oil on the surface to prevent rust;
	Bare pipe without painting:
	Epoxy painting/FBE coating/3PE coating
Pipe End	Plain end/ Bevel end;Groove end;
	Joint with flange;Threaded on two ends, one end with coupling, one end with plastic cap
Marking	As per client requirement or mill standard
	Painting method: Spray white paint
Packing	OD not less than 273mm: Loose packing,piece by piece.
	OD less than 273mm: In hexagonal seaworthy bundles packed by steel strips.
	Small sizes nested into big sizes.
Applications	Construction / building materials steel pipe
	Steel structure
	Scaffolding pipe
	Fence post steel pipe
	Fire protection steel pipe
	Greenhouse steel pipe
	Low pressure liquid, water, gas, oil, line pipe
	Irrigation pipe
	Handrail pipe
Techinical	ERW (high - frequency welded)
Trade Term	FOB, CFR, CIF, EXW, FCA
Payment Term	T/T, LC
Delivery Time	15-45 days (based on quantity) after receiving advanced payment by T/T or LC .
Main Market	Southeast Asia, South Asia, Middle East, Europe,
	Middle&South America, Africa and Oceania

Our Service advantages:

1.The steel supplied by our company is enclosed with the original material book of the steel factory.
2.Customers can choose any length or other requirements they want.
3.Ordering or purchasing all kind of steel products or special specifications.
4.Adjust the temporary lack of specifications in this library, saving you from the trouble of rushing to purchase.
5.Transport services, can be delivered directly to your designated place.
6.The materials sold, we are responsible for the overall quality tracking, for you to eliminate worries.

Galvanized steel tube are widely used in various industries due to their corrosion-resistant properties. The main uses of galvanized steel pipes include:
1.Construction: Galvanized steel pipes are commonly used in construction projects such as building frames, scaffolds, and handrails due to their durability and strength.
2. Plumbing: Galvanized steel pipes are also used in plumbing applications as they are resistant to corrosion and can withstand high water pressure.
3. Agriculture: Galvanized steel pipes are used in agricultural applications such as irrigation systems and animal enclosures.
4. Automotive: Galvanized steel pipes are used in the automotive industry for exhaust systems, structural components, and suspension systems.
5. HVAC: Galvanized steel pipes are used in heating, ventilation, and air conditioning systems due to their resistance to corrosion and ability to withstand high temperatures.
Overall, galvanized steel pipes are a versatile and reliable choice for a wide range of applications due to their durability, strength, and corrosion-resistant properties.
