Voltage Ratting: 58VDC
Operating Temp Range: -40℃~200℃
1-40 AMP 58V ATC/ATO Standard Regular Fuse Blade
2 year ago
Product details
Product Description
|
Product Name
|
58V PC ATC Auto Fuse
|
|
Material
|
Ag plated zinc alloy terminals+Housing Material Nylon
|
|
Package
|
1000pcs/bag, also can be packed in box
|
Voltage Ratting: 58VDC
Operating Temp Range: -40℃~200℃
Detailed Images
|
Catalog No.
|
Ampere Rating
|
Voltage Rating
|
Cold Resistance
|
Color Marking
|
|
Part Number
|
Current Rating
|
Voltage DC
|
Cold Resistance
|
Case color
|
|
ADATC-NL3-01
|
1A
|
58V
|
60.88mΩ
|
Black
|
|
ADATC-NL3-02
|
2A
|
58V
|
33.6mΩ
|
Gray
|
|
ADATC-NL3-03
|
3A
|
58V
|
23.75mΩ
|
Purple
|
|
ADATC-NL3-05
|
5A
|
58V
|
17.75mΩ
|
Tam
|
|
ADATC-NL3-7.5
|
7.5A
|
58V
|
10.58mΩ
|
Brown
|
|
ADATC-NL3-10
|
10A
|
58V
|
7.82mΩ
|
Red
|
|
ADATC-NL3-15
|
15A
|
58V
|
4.58mΩ
|
Blue
|
|
ADATC-NL3-20
|
20A
|
58V
|
3.21mΩ
|
Yellow
|
|
ADATC-NL3-25
|
25A
|
58V
|
2.36mΩ
|
Natural
|
|
ADATC-NL3-30
|
30A
|
58V
|
1.58mΩ
|
Green
|
|
ADATC-NL3-35
|
35A
|
58V
|
1.5mΩ
|
Light Green
|
|
ADATC-NL3-40
|
40A
|
58V
|
1.35mΩ
|
Orange
|
The type of car fuse used depends on the specific make and model of the car, as well as the electrical system and components. Common types of car fuses include blade fuses (ATC, ATO, Mini, Maxi), glass tube fuses, and ceramic fuses. It is important to consult the car's owner manual or a professional to determine the correct type and rating of fuse for a specific application.
