Paper Roll Wrapper with Kraft
3 year ago
Reel radial wrapper is designed to integrate the main wrapping machine with driving rollers, can be designed to be automatic or semi-auto. Auto wrapper is integrated with V-slat reel conveyor, to realize auto reel infeed, auto wrapping and auto reel outfeed.
Radial wrapper parts
Motorised pre-stretch film delivery unit
Gear and rack driving device.
Precise straight railway.
Steel frame and powder coating.
Whole set of pneumatic control system, user connects to the stop valve inlet.
The necessary control box, all the proximity switch and photo-eye frame.
Auto hot melt glue spray device, auto film press device, auto film cut device, auto film sticking device.
Capacity: 30-90 rolls/hour (standard film layers: 2 layers).
Hot melt glue spray brand: Nordson.
V-slat conveyor with lift
Total conveyor length: 3000-4500mm, subject to final requirement;
Reel lifting roller 1set
Driving roller 2pcs, includes one roller with motor, surface chrome-plating thickness 50um, diameter Ф200mm (subject to final design).
Motor designed with inverter and brake.
Electrical/Hydraulic lift.
Driving roller frame 1 set
Driving roller lifting hydraulic system 1 set, including the oil box, oil pump, various valves, motor, chilling device and all pipeline and parts.
Chilling water pipe is connected to the stop valve inlet and outlet by the user.
