API 11E Conventional Walking Beam Pumping Unit

Brief Introduction
Conventional pumping units with walking beams, balanced by cranks, are among the most common and most widely used power units in rod production on oil fields.Products comply with Specifications of Pumping Units (API Spec 11E) and other related standards, and have acquired the authorization to use Official API Monogram.

Technical Performance & Characteristics
1.Modular and virtual manufacturing technologies are adopted in design, so that the structure of products is optimized and components are highly standardized, generalized and seriated.
2.Key structural elements are subject to finite element analysis to ensure stable performance and high reliability.
3.Reducers are driven by double-arc symmetrical split or involute herringbone wheels that are properly sealed and distinguished with low noise, smooth operation, reliable and durable service.
4.The entire machine features simple operation and maintenance and extended service life.

API 11E oilfield equipment pumping unit for oil production

We produced the pumping unit which varieties complete and wide coverage, it can meet production conditions different needs of the domestic and international oilfield. Company annual production capacity has reached more than 500 Tai, and has adopted GB/T19001(ISO9001)quality certification system and API 11E certification.

Because of simple structure, high reliability, easy operation and installation, Conventional beam pumping unit is given a warm welcome by users. The profiled beam pumping unit have the merits of the conventional beam pumping unit but also have the distinctive features with stroke length , stock per minute low, and significant energy saving effect. And we have been designed and developed 9 series models include CYJS3,4,5,6,8,10,12,14,16 of Conventional beam pumping unit and profiled beam pumping unit.

The profiled beam pumping unit is the promotion projects of China National Petroleum Corporation and the National Science and Technology Achievements. The aircraft is used for low and high viscosity crude oil exploitation of the aquifer long stroke of energy-efficient pumps Everyone can also be used for oil exploitation. The aircraft used adjustable arc-shaped beam after the boom, the beam between he beams and used flexible connectivity structure, not only retains the advantages of the conventional machine, but also a long stroke, dynamic load small, low energy consumption, high efficiency, stable, easy to start and so on. Currently, we have developed 6 series models include CYJS6,8,10,12,14 etc, and it is promoted in many oil fields of the country.

1. Carry out API 11E standards strictly.

2. Reducer with API production qualification.

3. Complete production tooling.

4. The use of forgings in key parts.

5. Engineers available to service machinery overseas

1. "H" section steel structure, high strength and nice load bearing capacity.

2 .Middle width roller center bearing, strong endurance. Self-aligning bearings are adopted in equalizer beam bearing and crank pin bearing, reducing installationerrors and the vibration when pumping unit is operating.

3. Hanging structure of the horsehead is "self-abdicating" mechanism , facilitating wellhead operations.

Gear reducer adopts herringbone involute or double circular toothed gear, high precision, nice load bearing capacity, and long service life.

4. Brake adopts internal expanding or external structure . The brake has safety devices, which can brake quickly, safe and reliable.

5. Lubrication grease is supplied by central lubrication system, reducing manual maintenance.

6. The unit has comprehensive safety protection, the ladder and all moving parts are equipped with safety guard and safety fences.

Product Specification

NO.	Model	Load Rating (lbs)	Stroke length (in)	Stroke frequency (min -1)
1	C-40D-76-48	7600	48;37;26	6;9;12
2	C-57D-76-54	7600	54;41;28	6;9;12
3	C-80D-133-54	13300	54;43;31	6;9;12
4	C-80D-119-64	11900	64;52;40	6,8,10
5	C-114D-119-86	11900	86;76;59	6,8,10
6	C-114D-143-64	14300	64;52;40	6,8,10
7	C-114D-143-74	14300	74;62;50	6,8,10
8	C-160D-173-86	17300	86;74;61	6,8,10
9	C-160D-200-76	20000	76;62;51	6,8,10
10	C-228D-213-120	21300	120;102;85	5,7,9
11	C-228D-246-86	24600	86;74;61	5,7,9
12	C-228D-173-100	17300	100;86;71	5,7,9
13	C-320D-305-120	30500	120;102;85	5,7,9
14	C-320D-256-120	25600	120;100;86	5,7,9
15	C-456D-305-120	30500	120;102;85	5,7,9
16	C-456D-305-144	30500	144;124;106	4,6,8
17	C-640D-365-144	36500	144;124;106	4,6,8
18	C-640D-365-168	36500	168;142;116	4,6,8
19	C-640D-305-168	30500	168;142;116	4,6,8
20	C-640D-365-192	36500	192;164;136;110	4,5,6
21	C-912D-365-144	36500	144;124;106	4,6,8
22	C-912D-365-168	36500	168;142;116	4,6,8
23	C-912D-305-192	30500	192;168;135;120,95,74	4,5,6
24	C-912D-365-192	36500	192;164;136;110	4,5,6
25	C-912D-427-144	42700	144;124;106	4,6,8
26	C-912D-427-168	42700	168;142;116	4,6,8
27	C-912D-427-192	42700	192;164;136;110	4,6,8
28	C-1280D-365-192	36500	192;164;136;110	4,5,6
29	C-1280D-427-192	42700	192;164;136;110	4,5,6
30	C-1280D-427-216	42700	216,192;168;144	4,5,6
31	C-1280D-427-240	42700	240;207;175;145	4,5,6
32	C-1824D-427-192	42700	192;164;136;110	4,5,6
33	C-1824D-427-216	42700	216;192;168;145	4,5,6
