Photovoltaic Diode SBR12A45V
10 month ago
Product details
P/N: YZPST-SBR12A45V Photovoltaic Diode
YZPST brand 12A SBR12A45V Photovoltaic Diode
SPECIFICATION
Characteristic | Symbols | SBR12A45V | Unit | ||
Maximum repetitive peak reverse voltage | VRRM | 45 | V | ||
Maximum average forward rectified current | IFM | 12 | A | ||
Peak forward surge current 8.3 ms single half sine-wave | IFSM | 200 | A | ||
Typical thermal resistance | RθJA | 66 | °C/W | ||
Operating Temperature Range | VR ≤ 80% VRRM | TJ | -65 to +150 | °C | |
DC Forward Mode | TJ | ≤200 | °C | ||
Storage Temperature Range | TSTG | -65 to +175 | °C | ||
Forward Voltage Drop | IF = 12A | VF | 0.49 | V | |
Leakage Current | IR | 0.12 | mA |
