The hydraulic pump safety valve is an important component in the hydraulic system. This valve is used at the set pressure, so that components of the hydraulic system will not malfunction due to excessive pressure. When the system pressure is too high, the safety valve opens, allowing hydraulic oil to return to the tank body to protect the system. This valve serves to protect the lifespan of the hydraulic power unit, and users can adjust its pressure so that it can set pressure requirements in any situation.
Specification
|
Place of Origin
|
China
|
|
Model number
|
RV08-22
|
|
Rated pressure
|
221bar
|
|
Rated flow
|
30.2 L/min
|
|
Mounting torque
|
27.1 Nm (Max)
|
|
Valve pass number
|
VC08-2
|
|
Temperature range
|
-40℃-120℃
|
|
Leakage rate
|
0.25 ml/min (Max) when closed
|
|
Weight
|
0.23kg
|
|
Medium
|
Mineral oil with a viscosity of 7.4-420cSt or synthetic oil with lubricating effect
|
